Airtac X-APH Hex Head Elbow Adapter X-APH12M12
$4.31
Regular price
$11.81
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APH12M12
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APH12M12 Hexagonal Elbow Joint Technical Details
- Model: X-APH12M12
- Type: Swivel elbow joint with external hex design
- Body material: Anodized aluminum alloy (AL6061-T6)
- Thread specification: M12×1.5 male thread (ISO 1179-2 standard)
- Maximum torque resistance: 15 N·m
- Working pressure range: 0-1.0 MPa
- Temperature tolerance: -20℃ to +80℃
- Surface hardness: HV 400±20
- Rotational angle: 360° continuous rotation
- Seal type: Dual NBR O-rings (70±2 Shore A)
- IP rating: IP54 (dust protected, splash resistant)
- Weight: 38±2 grams
- Dimensions: 32mm(L) × 20mm(W) × 28mm(H)
Precision-machined pivot joint featuring anti-vibration ball bearing structure and self-lubricating bushings. The 7-step anodization process ensures corrosion resistance in humid environments. Integrated leak-proof design maintains 0.01mL/min max air leakage at 0.5MPa.
Installation Scenarios:
- Robotic arm pneumatic tool changers
- CNC machine coolant line connections
- Automated assembly line gripper rotations
- Food processing equipment (FDA-compliant grease)
- Semiconductor wafer handling systems
Mounting guidance:
Apply 2-3Nm pre-torque before final tightening to 12-14Nm.
Use thread sealant only on male threads, avoiding contact with
swivel mechanism. Maximum recommended cyclic rotation: 60 RPM.
| Property | Property Value |
|---|---|
| sku | X-APH12M12 |
