Airtac X-APH Hex Head Elbow Adapter X-APH12M20
$6.42
Regular price
$13.92
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APH12M20
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APH12M20 Hexagonal Elbow Joint Technical Details
- Model: X-APH12M20
- Type: External hexagonal swivel elbow joint
- Thread specification: M20×1.5 (metric fine thread)
- Material: Aluminum alloy body with nickel plating
- Seal material: NBR (Nitrile rubber)
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Surface hardness: HV 0.3/5 ≥450 (anodized treatment)
- Thread torque resistance: 25-30 N·m
- Rotation angle: 360° continuous rotation
- Weight: 78g ±2g
- Dimensions: 32mm(L) × 24mm(W) × 24mm(H)
- Vibration resistance: 10-2000Hz, 20m/s² max
- Corrosion protection: 96hr salt spray test compliant
Precision-engineered swivel joint featuring anti-vibration grooves and triple-seal structure (primary O-ring + backup ring + thread seal). The hexagonal design allows wrench tightening while maintaining 360° fluid path alignment. Anodized surface prevents galling during installation.
Industrial Applications:
- Pneumatic cylinder piping in robotic welding arms
- High-cycle automation equipment requiring rotational freedom
- Mobile hydraulic systems with space constraints
- Plastic injection molding machine air circuits
- CNC machine tool cooling air supply lines
Installation protocol:
Apply thread sealant only on male threads (not on joint body).
Use 27mm open-end wrench for installation.
Maximum recommended re-tightening cycles: 5 times.
Fluid compatibility:
Compressed air (ISO 8573-1:2010 Class 3.4.2),
Lubricated air (ISO VG32 or equivalent),
Not suitable for phosphate ester fluids or strong alkalis
| Property | Property Value |
|---|---|
| sku | X-APH12M20 |
