Airtac X-APH Hex Head Elbow Adapter X-APH401
AirTAC X-APH401 Hexagonal Elbow Joint Specifications
- Model: X-APH401
- Type: Swivel male elbow with hex base
- Thread specification: M5×0.8 female thread (internal)
- Material:
- Body: Chromium-plated brass C3604
- Seal: HNBR (Hydrogenated Nitrile) O-ring
- Swivel component: Special nylon composite
- Pressure rating: 0.05-1.0 MPa (7-145 psi)
- Temperature range: -20℃ to 80℃ (continuous use)
- Peak torque resistance: 4.5 N·m max
- Weight: 18.2±0.3g (0.64 oz)
- Dimensions:
- Height: 28.5mm (1.12")
- Hex width: 8mm (0.315") across flats
- Thread depth: 6.5mm (0.256")
- Swivel angle: 360° continuous rotation
- Surface treatment: Electroless nickel plating (5-8μm)
- Vibration resistance: 10-2000Hz, 3G acceleration
- Compliance: RoHS 2011/65/EU
Precision-engineered swivel joint featuring dual-seal technology with leak-proof performance under dynamic motion. The hardened hex base prevents rounding during installation, while the low-friction nylon swivel maintains smooth rotation even after 500,000+ cycles. Compatible with air, inert gases, and water-glycol mixtures.
- Pneumatic tool quick-connect systems
- Multi-axis robotic end effectors
- CNC machine coolant line connections
- Semiconductor wafer handling equipment
- Packaging machine rotary unions
- Medical device pneumatic circuits
Installation protocol:
Apply 1.5-2 wraps of PTFE tape on male threads (if used).
Tighten with 8mm wrench to 2.8-3.2 N·m torque.
Avoid overtightening which may compress O-ring beyond 15% deformation limit.
| Property | Property Value |
|---|---|
| sku | X-APH401 |
