Airtac X-APH Hex Head Elbow Adapter X-APH402
$3.89
Regular price
$11.39
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APH402
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APH402 Hexagonal Elbow Joint Technical Details
- Model: X-APH402
- Type: Swivel elbow joint with external hexagon drive
- Material: Nickel-plated brass body + POM (polyoxymethylene) seal
- Thread specification: G1/8 (ISO228-1 standard)
- Pressure range: 0.05-1.5 MPa
- Temperature range: -20℃ to 80℃
- Swivel angle: 360° continuous rotation
- Seal hardness: 90±2 Shore A
- Surface roughness: Ra ≤1.6μm
- Hex size: 12mm across flats
- Weight: 32±2g
- Dimensions: 40mm(L) × 12mm(W) × 16mm(H)
- Certification: RoHS compliant
Precision-machined elbow connector featuring anti-vibration swivel design with dual O-ring seals. The nickel-plated construction resists hydraulic oil degradation and atmospheric corrosion. Optimized flow path reduces turbulence by 18% compared to standard elbows.
Ideal for:
- Compact pneumatic tool connections
- Robotic arm end-effector piping
- CNC machine coolant line adapters
- Medical gas delivery systems
- Semiconductor equipment manifolds
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads (clockwise wrapping).
Tighten to 12-15N·m torque using 12mm hex key. Avoid overtightening
which may deform POM seals. Perform pressure test at 1.8MPa after installation.
| Property | Property Value |
|---|---|
| sku | X-APH402 |
