Airtac X-APH Hex Head Elbow Adapter X-APH4M12
$3.89
Regular price
$11.39
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APH4M12
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APH4M12 Hex Elbow Joint Specifications
- Model: X-APH4M12
- Type: External hexagon elbow joint (swivel type)
- Thread specification: M12×1.5 (male thread)
- Hex size: 14mm wrench flat
- Material: Nickel-plated brass (C3604)
- Working pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Surface roughness: Ra ≤3.2μm
- Max torque resistance: 18 N·m
- Weight: 32g ±2g
- Dimensions: 45mm(L) × 14mm(W) × 22mm(H)
- Vibration resistance: 10–55Hz, 1.5mm amplitude
- Thread tolerance: 6g per ISO 965-1
Precision-engineered 90° pneumatic connector with anti-vibration swivel design, featuring double O-ring seals for leak-free operation under dynamic loads. The nickel plating provides corrosion resistance in humid environments. Compatible with ISO 1179-2 standard fittings.
Typical Applications:
- Robotic arm pneumatic tool changers
- CNC machine tool coolant line connections
- Packaging machinery rotary unions
- Automated assembly line jig fixtures
- Semiconductor equipment gas distribution
Installation guidelines:
Use 14mm crowfoot wrench for torque-controlled assembly (max 12 N·m).
Apply thread sealant only on male threads, avoiding contact with O-rings.
Perform pressure test at 1.5× working pressure after installation.
| Property | Property Value |
|---|---|
| sku | X-APH4M12 |
