Airtac X-APH Hex Head Elbow Adapter X-APH4M6
$3.58
Regular price
$11.08
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APH4M6
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APH4M6 Hexagonal Elbow Joint Technical Details
- Model: X-APH4M6
- Type: Swivel elbow joint with hex base
- Thread specification: M6×1.0 external thread (male)
- Material: Nickel-plated brass body
- Seal material: NBR (Nitrile) O-ring
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Tube OD compatibility: 4mm (5/32") pneumatic tubing
- Rotation angle: 360° swivel capability
- Hex size: 8mm wrench flat
- Torque limit: 0.8-1.2 N·m (7-10.6 lb-in)
- Weight: 6.2g ±0.3g
- Dimensions: 18mm(L) × 12mm(W) × 14mm(H)
- Surface treatment: Electroless nickel plating (5-8μm)
Precision-machined elbow connector featuring leak-resistant dual-seal design with 15° angled port orientation. The hex base allows secure tool tightening while maintaining 360° rotational alignment flexibility. Corrosion-resistant plating ensures durability in humid environments.
Typical Applications:
- Compact pneumatic tool connections
- Robotic arm end-effector air supply
- Medical device gas line routing
- CNC machine tool coolant control systems
- Food processing equipment air manifolds
Installation protocol:
Use 8mm open-end wrench for assembly. Apply thread sealant (LOCTITE 545)
to male threads before installation. Max 120° reorientation cycles recommended.
| Property | Property Value |
|---|---|
| sku | X-APH4M6 |
