Airtac X-APH Hex Head Elbow Adapter X-APH4M8
AirTAC X-APH4M8 Hexagonal Elbow Joint Technical Details
- Model: X-APH4M8
- Series: X-APH (Heavy Duty Elbow Connector)
- Thread specification: M8×1.0 (Male Thread)
- Material: High-strength brass alloy (CuZn39Pb3)
- Surface treatment: Electroless nickel plating (5-8μm thickness)
- Hex size: 10mm AF (Across Flats)
- Max operating pressure: 1.5 MPa (217 psi)
- Proof pressure: 3.0 MPa
- Burst pressure: ≥6.0 MPa
- Temperature range: -20℃ to 120℃ (static), -5℃ to 80℃ (dynamic)
- Seal type: Integrated NBR O-ring (70±5 Shore A)
- Torque resistance: 3.5 N·m max installation torque
- Weight: 12.5g ±0.3g
- Dimensions: 22mm(L) × 10mm(W) × 16mm(H)
- Fluid compatibility: Air, inert gases, vacuum
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Certifications: RoHS compliant, REACH SVHC-free
Precision-engineered 90° pneumatic connector featuring anti-vibration grooves and double-sealing structure. The hexagonal base allows wrench tightening while the elbow design enables compact piping layouts. Nickel plating provides corrosion resistance in humid environments (salt spray tested to 96hrs).
- Use 10mm open-end wrench for installation
- Apply 2.0-3.0 N·m torque (PTFE tape optional)
- Maximum 3 full rotations after hand-tight
- Orientation: Rotatable 360° after installation
- Robotic arm pneumatic tool changers
- CNC machine tool clamp circuits
- Semiconductor wafer handling systems
- High-cycle packaging machinery
- Medical gas control panels
Maintenance note:
Inspect O-ring every 500,000 cycles. Replace if compression set exceeds 15%.
Lubricate with PFPE-based grease for vacuum applications.
| Property | Property Value |
|---|---|
| sku | X-APH4M8 |
