Airtac X-APH Hex Head Elbow Adapter X-APH601
$3.58
Regular price
$11.08
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APH601
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APH601 Hexagonal Elbow Joint Specifications
- Model: X-APH601
- Type: Reusable 90° elbow thread connector
- Thread specification: G1/8 (BSPP)
- Tube compatibility: Φ6mm (1/4") OD pneumatic tubing
- Material: Nickel-plated brass body + PPS plastic sleeve
- Pressure rating: 0.05-1.0 MPa (7-145 PSI)
- Temperature range: -20℃ to 80℃ (continuous) / 120℃ peak
- Hex size: 12mm wrench flat
- Surface treatment: Electroless nickel plating (5-8μm)
- Seal type: Integrated NBR O-ring (Shore A70±5)
- Weight: 18.5g ±0.3g
- Dimensions: 25.4mm(L) × 16mm(W) × 22.3mm(H)
- Vibration resistance: 10-2000Hz, 15G acceleration
- IP rating: IP54 (dust protected, water splashed)
High-density hexagonal elbow connector with 45° swivel capability for tight spaces. Features dual-locking teeth for anti-rotation and torque-resistant design. Compatible with air, inert gases, and vacuum systems (not for hydraulic fluids). Includes built-in dust cap retention groove.
Typical Applications:
- Robotic arm pneumatic tool changers
- CNC machine tool coolant line connections
- Semiconductor wafer handling equipment
- Packaging machine rotary union interfaces
- Medical gas panel distribution systems
Installation note:
Apply 1.2-1.5N·m torque during assembly. For optimal sealing,
insert tube until hearing a "click" from the collet mechanism.
Rotate fitting 30° after initial tightening for uniform compression.
| Property | Property Value |
|---|---|
| sku | X-APH601 |
