Airtac X-APH Hex Head Elbow Adapter X-APH602
AirTAC X-APH602 Hex Elbow Union Fitting Technical Details
- Model: X-APH602
- Type: Swivel-type male elbow with hex base
- Material: Brass (nickel-plated surface)
- Thread Standard: M5×0.8 male thread × 1/8" BSPP female thread
- Rotation Angle: 360° free rotation capability
- Working Pressure: 0.05-1.5 MPa (7-217 psi)
- Temperature Range: -5℃ to 80℃ (23°F to 176°F)
- Installation Torque: 0.5-0.7 N·m (4.4-6.2 lb-in) recommended
- Seal Material: NBR (Nitrile) O-ring
- Surface Treatment: Electroless nickel plating (5-8μm thickness)
- Weight: 78g ±2g
- Dimensions: 32mm(L) × 19mm(W) × 24mm(H)
- Alternative Thread Options: NPT available upon request
Precision-engineered swivel fitting featuring dual sealing surfaces and corrosion-resistant nickel plating. The hexagonal base allows tool-assisted tightening in confined spaces, while the 360° rotating elbow enables flexible tubing routing. Compatible with both pneumatic and low-pressure hydraulic systems (non-lubricated media).
- Pneumatic cylinder port connections
- Modular automation equipment manifolds
- Packaging machine tooling interfaces
- Semiconductor manufacturing gas lines
- Food processing equipment air supply
- Robotic end-effector pneumatic routing
Installation guidance:
Apply PTFE tape to male threads using clockwise winding pattern.
Avoid overtightening - maximum torque not to exceed 1.2 N·m.
For vertical installations, orient hex base downward to prevent particulate accumulation.
| Property | Property Value |
|---|---|
| sku | X-APH602 |
