Airtac X-APH Hex Head Elbow Adapter X-APH6M10
AirTAC X-APH6M10 Hexagonal Elbow Joint Specifications
- Model: X-APH6M10
- Type: Swivel-type male elbow with hex base
- Material: Stainless steel body + brass swivel
- Thread specification: M10×1.0 male thread
- Max torque resistance: 8.5 N·m
- Pressure rating: 0.05-1.0 MPa
- Temperature range: -20℃ to 150℃
- Surface treatment: Electroless nickel plating
- Seal type: NBR O-ring (oil-resistant)
- Hex size: 17mm AF (across flats)
- Weight: 38g ±2g
- Dimensions: 42mm(L) × 24mm(W) × 32mm(H)
- Rotational angle: 360° continuous rotation
- Vibration resistance: ≤15Hz (with lock nut)
- IP rating: IP54 (dust protected, splash resistant)
Precision-machined pivot joint featuring dual-axis adjustability with anti-vibration locking. The hexagonal base allows tool-assisted tightening in confined spaces, while the rotating elbow maintains consistent airflow during directional adjustments. Corrosion-resistant construction withstands hydraulic oils and mild chemicals.
- Robotic arm end-effector pneumatic connections
- CNC machine tool coolant line adapters
- Packaging machinery rotary union interfaces
- Mobile hydraulic systems requiring vibration dampening
- Semiconductor fab equipment gas line junctions
Installation protocol:
Apply 2-3 drops of thread sealant (LOCTITE 577 recommended) before assembly.
Tighten using 17mm crowfoot wrench at 6.5-7.2 N·m torque.
Perform 5 full rotation cycles post-installation to seat seals properly.
| Property | Property Value |
|---|---|
| sku | X-APH6M10 |
