Description
AirTAC X-APH6M12 Hexagonal Elbow Swivel Joint Specifications
- Model: X-APH6M12
- Type: Reusable 90° rotary swivel with hex nut
- Thread specification: M12×1.25 external thread (male)
- Material: Nickel-plated brass body + CRMo steel hex nut
- Max torque resistance: 35 N·m
- Pressure rating: 0.05-1.5 MPa (7-217 PSI)
- Temperature range: -20℃ to 150℃ (static) / -5℃ to 80℃ (dynamic)
- Tube compatibility: Ø6mm polyurethane/nylon tubing
- Seal type: Dual O-ring (FKM fluorocarbon rubber)
- Surface treatment: Electroless nickel plating (8-12μm)
- Weight: 58g ±2g
- Dimensions: 21mm(W) × 19mm(H) × 25mm(L)
- Vibration resistance: ≤20m/s²
- Certification: RoHS compliant
Precision-engineered rotary joint featuring 360° continuous rotation capability with leak-free sealing. The hexagonal base allows tool-assisted tightening while maintaining precise angular alignment. Anti-vibration design prevents self-loosening in high-cycle applications.
Typical Applications:
- Robotic arm end-effector pneumatic connections
- CNC machine tool coolant line adapters
- Semiconductor wafer handling equipment
- Food processing pneumatic rotary unions
- Automated packaging machine actuators
Installation protocol:
Apply 2-3 drops of pneumatic sealant (PST-3 type) on threads before assembly.
Tighten with 13mm wrench using 18-22N·m torque. Perform pressure test at
1.8MPa for 5 minutes post-installation.
Not compatible with phosphate ester hydraulic fluids or chlorinated solvents.
Max angular deflection under load: ±2° from neutral position.
| Property | Property Value |
|---|---|
| sku | X-APH6M12 |
