Airtac X-APH Hex Head Elbow Adapter X-APH6M16
AirTAC X-APH6M16 Hex Elbow Joint Technical Details
- Model: X-APH6M16
- Type: Reusable metric male elbow fitting with hex nut
- Thread specification: M16×1.5 (external)
- Material: Nickel-plated brass (C3604)
- Operating pressure: 0.05-1.5 MPa
- Temperature range: -20℃ to 80℃
- Seal type: Metal-to-metal seal with optional PTFE tape compatibility
- Surface treatment: Electroless nickel plating (8-12μm thickness)
- Hex size: 19mm wrench flat
- Weight: 148±2g
- Dimensions: 38mm(Length) × 19mm(Width across flats) × 32mm(Height)
- Max torque: 35N·m (dry), 28N·m (lubricated)
- Compliance: RoHS compliant
Precision-engineered 90° flow connector featuring cold-forged construction for enhanced durability. The hexagonal base allows tool-assisted tightening in confined spaces, while the nickel plating provides corrosion resistance in humid environments. Designed for 10,000+ mating cycles without thread degradation.
- Pneumatic cylinder port connections
- Modular assembly systems requiring angled tubing runs
- Hydraulic test bench configurations
- Food processing equipment with frequent disassembly needs
- Robotic arm pneumatic circuits
Installation protocol:
Apply 2-3 wraps of PTFE tape clockwise on male threads.
Hand-tighten before final torque application.
Avoid overtightening - use calibrated torque wrench for >25N·m applications.
| Property | Property Value |
|---|---|
| sku | X-APH6M16 |
