Airtac X-APH Hex Head Elbow Adapter X-APH6M20
$6.11
Regular price
$13.61
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APH6M20
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APH6M20 Hexagonal Elbow Joint Technical Details
- Model: X-APH6M20 (External Hexagon Type)
- Body material: Nickel-plated brass (CuZn39Pb3)
- Thread specification: M20×1.5 (ISO 228-1 compliant)
- Rotation angle: ±25° adjustable swivel
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Seal material: NBR/FKM optional
- Surface hardness: ≥HV200 (nickel coating)
- Installation torque: 35-40 Nm (recommended with torque wrench)
- Weight: 218±5g (with packaging)
- Dimensions: 52mm(Ø) × 72mm(H) (hexagon width: 30mm)
- Pressure test: 1.5 MPa leakage test (JIS B8381 standard)
- Vibration resistance: 10-2000Hz, 1.5mm amplitude
High-torque elbow joint featuring 360° rotatable collar for flexible piping alignment. Anti-vibration design with dual O-ring seals ensures leak-proof connections in dynamic systems. Nickel plating provides corrosion resistance against water/steam exposure.
Implementation Scenarios:
- Robotic welding arm pneumatic circuits
- CNC machine tool coolant line connections
- High-cycle packaging machinery air supply
- Foundry equipment with thermal cycling demands
- Shipboard pneumatic systems requiring salt spray resistance
Installation protocol:
Apply PTFE tape clockwise on male threads (2-3 wraps).
Hand-tighten before final torque application.
Avoid side-load forces exceeding 150N during operation.
| Property | Property Value |
|---|---|
| sku | X-APH6M20 |
