Airtac X-APKB Connector - Threaded 5 Port X-APKB1003
AirTAC X-APKB1003 Threaded Manifold Connector Technical Details
- Model: X-APKB1003
- Type: 5-port threaded manifold (compact series)
- Port configuration: 1 input + 4 output ports
- Thread standard: M5×0.8 (metric fine thread)
- Material: Anodized aluminum alloy (AL6063-T5)
- Pressure rating: 0.05-1.0 MPa (7-145 PSI)
- Temperature range: -20℃ to 80℃ (static) / -5℃ to 60℃ (dynamic)
- Seal type: Integrated NBR O-rings (pre-lubricated)
- Flow capacity: 250 NL/min @ 0.5 MPa
- Weight: 78g ±2g
- Dimensions: 50mm(L) × 30mm(W) × 30mm(H)
- Surface hardness: HV 12-15 (anodized layer)
- Corrosion resistance: 96hr salt spray test passed
High-density distribution block designed for modular pneumatic systems, featuring precision-machined internal channels (Ø2.5mm nominal bore) that minimize pressure drop. The gold-anodized surface treatment provides enhanced wear resistance against repeated component installations. Includes pre-installed color-coded sealing caps (black for exhaust ports).
- Multi-valve manifold assemblies in SMC systems
- Compact pneumatic control cabinets
- Robotic end-effector air distribution
- Medical device pneumatic circuit consolidation
- Semiconductor manufacturing equipment
Installation protocol:
Apply 0.3-0.5Nm torque during installation using a calibrated torque wrench.
Sequential tightening pattern required - first secure center port (IN), then alternate between output ports diagonally.
Maximum 3 re-use cycles recommended for optimal sealing performance.
| Property | Property Value |
|---|---|
| sku | X-APKB1003 |
