Airtac X-APKB Connector - Threaded 5 Port X-APKB1203
AirTAC X-APKB1203 Threaded Five-Way Union Connector Specifications
- Model: X-APKB1203
- Type: 5-port threaded manifold (ISO standard)
- Body material: Brass with nickel plating
- Thread specifications:
- Port 1: PT1/8 (G1/8 equivalent)
- Ports 2-5: PT1/4 (G1/4 equivalent)
- Pressure range: 0-1.0 MPa (145 PSI)
- Temperature range: -5℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Thread engagement depth: 8±0.5mm
- Weight: 62g ±2g
- Dimensions:
- Length: 48mm (center-to-center between end ports)
- Width: 32mm (maximum body width)
- Height: 22mm (port face to base)
- Surface roughness: Ra ≤3.2μm
- Certification: RoHS compliant
High-density pneumatic distribution block designed for multi-circuit pneumatic systems. Features precision-machined internal channels (Ø3.5mm flow path) with cross-talk prevention design. Anti-vibration construction maintains seal integrity under mechanical stress. Compatible with air, inert gases, and vacuum applications.
- Multi-cylinder pneumatic control systems
- Packaging machine manifold clusters
- Automated assembly line distribution nodes
- Laboratory pneumatic instrument hubs
- Robotic end-effector air supply distribution
Installation guidelines:
Apply 2-3 wraps of PTFE tape on male threads (do not over-tighten beyond 15N·m torque).
Maintain 5mm minimum clearance between adjacent components for thermal expansion.
Perform pressure test at 1.5x operating pressure during initial commissioning.
| Property | Property Value |
|---|---|
| sku | X-APKB1203 |
