Airtac X-APKB Connector - Threaded 5 Port X-APKB4M5
AirTAC X-APKB Threaded Manifold (5-Port) X-APKB4M5 Technical Details
- Model Code: X-APKB4M5
- Type: Modular threaded pentagon manifold
- Thread Specification: M5×0.8 (ISO metric fine)
- Port Configuration: 5 ports (1 inlet, 4 outlets)
- Material: Aluminum alloy 6063-T5
- Surface Treatment: Hard anodized (25-30μm thickness)
- Max Operating Pressure: 1.0 MPa
- Temperature Range: -20℃ to +80℃
- Seal Material: NBR (Nitrile Butadiene Rubber)
- Port-to-Port Spacing: 18mm center distance
- Weight: 18g ±0.5g
- Dimensions: 24mm(W) × 24mm(D) × 28mm(H)
- Flow Capacity: 120 NL/min (at 0.5 MPa)
- Mounting Torque: 0.5-0.7 N·m (M5 threads)
- Compliance: RoHS 2011/65/EU
Precision-machined manifold block with leak-proof design featuring dual O-ring seals (front and rear). The hexagonal geometry allows tool-free manual rotation for optimal tubing alignment. Anodized finish resists chemical corrosion and minimizes particulate generation. Compatible with all AirTAC ISO 15407-1 compliant valves.
- Multi-axis pneumatic actuator control clusters
- Compact valve terminal assemblies in robotics
- Laboratory analytical instrument gas distribution
- Modular pneumatic teaching systems
- Embedded control nodes in semiconductor handling equipment
Installation Protocol:
Apply 1.5-2 wraps of PTFE tape on male threads. Use through-hole mounting with M5×12mm SHCS (not included). Sequential tightening pattern required - first secure center port, then alternate between opposite ports. Max reconfiguration cycles: 15 times.
| Property | Property Value |
|---|---|
| sku | X-APKB4M5 |
