Airtac X-APKB Connector - Threaded 5 Port X-APKB6M12
AirTAC X-APKB6M12 Threaded Five-Way Fitting Specifications
- Model: X-APKB6M12
- Type: Compact threaded manifold connector (5-port)
- Thread standard: M12×1.0 (male thread)
- Port configuration: 1 input, 4 outputs (ISO 15218-1 compliant)
- Material: Aluminum alloy 6063-T5 with anodized treatment
- Operating pressure: 0.05–1.0 MPa
- Max burst pressure: 3.0 MPa
- Temperature range: -20℃ to 80℃
- Thread engagement depth: 10±0.5mm
- Surface hardness: HV 350-400
- Seal type: Integrated NBR O-ring (Shore A 70±5)
- Weight: 38±2g
- Dimensions: 34mm(L) × 28mm(W) × 24mm(H)
- Mounting torque: 3.5-4.5 N·m (recommended with thread lock)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
A high-density pneumatic distribution block featuring precision-machined flow channels for minimized pressure drop. The electroless nickel-plated internal surfaces prevent particle shedding, making it ideal for cleanroom-compatible systems. Compatible with both metric (ISO) and BSPP thread adapters via conversion sleeves.
- Multi-axis pneumatic gripper clusters in robotics
- Modular vacuum circuit distribution
- Compact valve terminal manifolds
- Medical device pneumatic control units
- Mobile hydraulic/pneumatic hybrid systems
Installation protocol:
Apply thread sealant to male ports only (PTFE tape or LOCTITE 577).
Use counter-rotation technique during assembly to prevent O-ring twisting.
Maximum 3 reconnection cycles recommended.
| Property | Property Value |
|---|---|
| sku | X-APKB6M12 |
