Airtac X-APKB Connector - Threaded 5 Port X-APKB802
AirTAC X-APKB802 Threaded 5-Way Fitting Specifications
- Model: X-APKB802
- Type: Threaded 5-way distribution block (Pneumatic manifold)
- Material: Anodized aluminum alloy (surface hardness HV≥12°)
- Thread standards: G1/8, M5, NPT1/8 (customizable)
- Max working pressure: 1.0 MPa (145 psi)
- Temperature range: -20℃ to 80℃
- Seal material: HNBR (Hydrogenated Nitrile) with PTFE coating
- Installation torque: 1.5-2.0 N·m (M5), 3.0-4.0 N·m (G1/8)
- Weight: 198±5g
- Dimensions: 78mm(L) × 46mm(W) × 32mm(H)
- Port configuration: 1 input, 4 outputs + 1 exhaust
- Surface roughness: Ra≤3.2μm (flow channels)
High-density pneumatic distribution block with precision-machined flow paths, featuring anti-corrosion treatment and multi-standard thread compatibility. The chamfered port design (R0.5mm) prevents O-ring damage during installation. Optimized internal channels reduce flow resistance by 18% compared to standard manifolds.
- Multi-cylinder synchronization systems in packaging machinery
- Modular pneumatic control stations for automotive assembly lines
- Compact valve terminal integration for robotic end effectors
- Laboratory pneumatic circuit prototyping boards
- Mobile equipment pneumatic distribution hubs
Installation protocol:
Apply thread sealant only on male threads (not required for tapered threads).
Use torque wrench for installation - over-tightening may deform flow channels.
Recommended maintenance: Inspect seals every 2,000 operating hours in high-humidity environments.
| Property | Property Value |
|---|---|
| sku | X-APKB802 |
