Airtac X-APUT Fitting - Full Copper Straight X-APUT1008
AirTAC X-APUT1008 All-Copper Straight Through Fitting Technical Details
- Model: X-APUT1008
- Type: Straight through connector (male thread both ends)
- Material: C3604 lead-free brass (RoHS compliant)
- Thread specification: G1/8 (ISO228-1 standard)
- Working pressure: 0.05-1.5 MPa
- Temperature range: -5℃ to 120℃
- Installation torque: 8-10 N·m max
- Seal type: Metal-to-metal contact (no additional sealant required)
- Surface treatment: Electro-nickel plated (3-5μm thickness)
- Weight: 42g ±2g
- Dimensions: 18mm(L) × 18mm(W) × 18mm(H)
- Flow coefficient (Cv): 0.15
High-density brass straight connector designed for high vibration environments, featuring precision-machined threads with ±0.01mm tolerance. The nickel-plated surface provides enhanced corrosion resistance exceeding 96hrs in salt spray tests. Optimized internal bore geometry minimizes pressure drop (ΔP < 0.02MPa at 1.5MPa).
- Pneumatic cylinder port extensions
- Modular FRL (Filter-Regulator-Lubricator) unit connections
- Industrial robot end effector plumbing
- Compressed air distribution manifolds
- Laboratory instrumentation air lines
Installation guidance:
Use torque wrench for assembly. Apply thread seal tape (PTFE) only on non-tapered threads.
Maximum 3 full rotations after hand-tight. Avoid overtightening to prevent thread deformation.
| Property | Property Value |
|---|---|
| sku | X-APUT1008 |
