Airtac X-APUT Fitting - Full Copper Straight X-APUT8
AirTAC X-APUT8 Full Brass Straight Threaded Connector Specifications
- Model: X-APUT8
- Thread standard: G1/8 (ISO228-1 compliant)
- Material: C3604 lead-free brass (CuZn39Pb3)
- Surface treatment: Electroless nickel plating (5-8μm)
- Pressure rating: 0.3-1.5 MPa (operating), 3.0 MPa (burst)
- Temperature range: -20℃ to 150℃
- Flow coefficient (Cv): 0.45
- Weight: 28g ±1g
- Dimensions: 24mm(Length) × 12.5mm(Hex width) × 8mm(Thread OD)
- Seal type: Metal-to-metal sealing (NPT requires sealant)
- Compliance: RoHS 2.0, REACH, ISO 1179-1
Precision-machined straight connector featuring cold-forged brass construction with anti-vibration knurling. Optimized internal bore design reduces turbulent flow (pressure drop <0.02MPa @1MPa). Corrosion-resistant nickel plating withstands 96hrs neutral salt spray test. Includes built-in O-ring groove for optional sealing (AS568-006 compatible).
- Pneumatic tool quick-connect systems
- Refrigeration unit service ports (R134a/R410a compatible)
- CNC machine lubrication line junctions
- Beverage dispenser CO₂ gas lines
- Medical gas console connections
Installation protocol:
Apply 2-3 wraps of PTFE tape clockwise when sealing. Tighten to 12-15N·m torque using 12mm wrench.
Avoid overtightening - maximum allowable rotation after seal contact is 1.5 turns.
- Body color: Natural brass (nickel plated)
- Thread end marking: Laser-etched "↑FLOW" directional indicator
- Pressure rating stamp: "1.5MPA" on hex flat
| Property | Property Value |
|---|---|
| sku | X-APUT8 |
