Airtac X-APX Adapter - Y-Type Threaded Tee X-APX601
AirTAC X-APX601 Y-Type Threaded Tee Fitting Specifications
- Model: X-APX601
- Type: Y-shaped threaded tee connector (equal distribution)
- Material: Brass (nickel-plated) / Optional stainless steel variant
- Port size: G1/8 (BSPP) female threads on all ports
- Thread standards: ISO 1179-1 compliant (alternative NPT threads available)
- Operating pressure: 0.05–1.5 MPa (7–217 PSI)
- Burst pressure: ≥4.5 MPa (653 PSI)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Seal material: HNBR rubber (standard) / FKM available for high-temp applications
- Surface roughness: Ra ≤3.2μm on flow paths
- Weight: 78g ±2g (brass version)
- Dimensions: 45mm(L) × 25mm(W) × 25mm(H) (port center-to-center distances)
- Flow coefficient (Cv): 0.15
- Leakage rate: <3 bubbles/min under 0.5 MPa air pressure
Precision-engineered Y-shaped pneumatic connector with triple-port design for balanced flow distribution. Features corrosion-resistant nickel plating and precision-machined threads for leak-free connections. The 120° branch angle minimizes pressure drop in multi-directional piping layouts.
- Modular pneumatic circuit splitting in automation cells
- Air supply distribution in packaging machinery
- Vacuum system branching for material handling
- Coolant line connections in CNC equipment
- Medical gas panel manifold systems
Installation guidelines:
Apply 2-3 wraps of PTFE tape on male threads (for BSPP). Tighten to 12-15 N·m torque.
Avoid overtightening - maximum allowable rotation after seal contact is 1.5 turns.
Use thread sealant compatible with system media (air, vacuum, inert gases).
Compatibility note:
Not suitable for continuous immersion or aggressive chemicals.
For oxygen systems, specify degreased version (X-APX601-OC).
| Property | Property Value |
|---|---|
| sku | X-APX601 |
