Airtac X-APX Adapter - Y-Type Threaded Tee X-APX801
AirTAC X-APX801 Y-Type Threaded Tee Connector Specifications
- Model: X-APX801
- Type: Y-shaped pneumatic tee connector
- Material: Brass with nickel plating (stainless steel optional)
- Thread standard: G1/8 (ISO228-1 compliant)
- Port configuration: 1 female thread inlet + 2 male thread outlets
- Pressure rating: 0.05-1.0 MPa
- Temperature range: -20℃ to 120℃
- Proof pressure: 1.5 MPa
- Seal material: NBR (Nitrile) rubber
- Surface roughness: Ra ≤3.2μm
- Weight: 28±2g
- Dimensions: 26mm(L) × 18mm(W) × 32mm(H)
- Torque resistance: ≤30N·m
- Fluid compatibility: Air, inert gases, non-lubricated fluids
Precision-engineered Y-shaped flow divider featuring corrosion-resistant construction and zero-leak design. The 60° branch angle optimizes flow distribution while maintaining compact dimensions. Compatible with all standard 1/8" pneumatic tubing systems.
- Pneumatic circuit branching in automation equipment
- Air pressure gauge manifold connections
- Modular pneumatic component integration
- Medical gas line distribution systems
- Robotic arm pneumatic networks
Installation guidelines:
Apply 1.5-2 wraps of PTFE tape on male threads. Use two wrenches during assembly -
hold base port stationary while tightening branch ports. Avoid overtightening beyond
12N·m torque to prevent thread deformation.
Environmental resistance: IP54-rated when properly installed. Not recommended for continuous chemical exposure. For vacuum applications, apply silicone grease to threads before assembly.
| Property | Property Value |
|---|---|
| sku | X-APX801 |
