Airtac X-APZR Cross Threaded Cross Fitting X-APZR401
AirTAC X-APZR401 Cross Threaded Four-Way Fitting Specifications
- Model: X-APZR401
- Type: Cross-type manifold with quadruple outlets
- Thread Standard: PT1/4 (BSPP) female threads on all ports
- Material: Lead-free brass CW617N (chrome-plated surface)
- Max Working Pressure: 1.5 MPa (217 psi)
- Temperature Range: -20℃ to 80℃ (non-freezing environment)
- Weight: 85g ±2g
- Dimensions: 40mm(W) × 40mm(H) × 40mm(D)
- Seal Type: Integrated O-ring (NBR material)
- Flow Capacity: 850 l/min (Cv value 0.6)
- Surface Treatment: Electroless nickel plating (8-12μm thickness)
- Torque Limitation: 14-16 N·m during installation
Precision-engineered four-way pneumatic connector featuring a symmetrical cross design for balanced flow distribution. The chrome-plated brass construction ensures corrosion resistance in humid environments, while the embedded O-ring provides leak-free performance under cyclic pressure. Designed for modular assembly in compact pneumatic manifolds.
- Multi-actuator control in assembly line automation
- Air distribution hubs for CNC machine tool clamps
- Modular pneumatic circuit prototyping
- Vacuum system flow splitting applications
- Simultaneous tool actuation in packaging machinery
Installation protocol:
Apply PTFE tape clockwise on male threads (2.5 wraps recommended).
Avoid overtightening - use torque wrench for precise 15N·m limit.
Compatible with ISO 1179-2 and JIS B0203 standards.
