Airtac X-APZR Cross Threaded Cross Fitting X-APZR601
AirTAC X-APZR601 Cross Thread Tee Fitting Technical Details
- Model: X-APZR601
- Type: 4-way cross connector (female threaded)
- Thread standard: Metric (M5×0.8)
- Material: Nickel-plated brass (C3604)
- Pressure rating: 0.2–1.5 MPa
- Burst pressure: ≥6 MPa
- Operating temperature: -20℃ to 120℃
- Seal type: Embedded O-ring (NBR)
- Surface roughness: Ra ≤3.2μm
- Weight: 22g ±0.5g
- Dimensions: 24mm(L) × 24mm(W) × 24mm(H)
- Port angles: 90° orthogonal distribution
- Vibration resistance: 10–2000Hz, 15G acceleration
- Certification: RoHS compliant
Precision-machined cross fitting with quadruple pressure pathways, featuring anti-vibration thread locking design. The nickel plating provides corrosion resistance in humid environments while maintaining stable conductivity for grounding requirements. Compatible with all standard 5mm OD pneumatic tubing.
- Multi-axis pneumatic robot joint distribution blocks
- CNC machine tool air circuit branching nodes
- Semiconductor fab equipment manifold systems
- High-cycle automation test rigs
- Medical gas distribution panels
Installation protocol:
Apply 0.3–0.5Nm torque during assembly. Use thread sealant only on male threads,
avoiding contact with O-ring surfaces. Perform pressure test at 1.25× operating
pressure after installation.
