Airtac X-APZR Cross Threaded Cross Fitting X-APZR604
$5.18
Regular price
$12.68
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-APZR604
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-APZR604 Cross Threaded Tee Fitting Specifications
- Model: X-APZR604
- Type: 4-way cross threaded connector (male thread)
- Thread standard: Metric (M)
- Thread size: M5 × 0.8
- Material: Nickel-plated brass (C3604)
- Surface hardness: ≥HV200
- Pressure rating: 1.5 MPa (15 bar)
- Temperature range: -5℃ to 120℃
- Proof pressure: 2.25 MPa
- Burst pressure: ≥3 MPa
- Weight: 18.5±0.5g
- Dimensions: 24mm(Length) × 24mm(Width) × 24mm(Height)
- Port configuration: Four M5 male threads (90° cross layout)
- Seal compatibility: Compatible with EPDM/NBR/PU seals
- Vibration resistance: 10-2000Hz, 2.5mm amplitude
- Certification: RoHS compliant
Precision-machined cross connector with electroless nickel plating for enhanced corrosion resistance. Features rolled threads for consistent sealing performance and anti-vibration lock structure. Designed for high-density pneumatic circuit branching in confined spaces.
Typical Applications:
- Multi-axis pneumatic tool changers
- Compact valve manifold assemblies
- Robotic gripper air distribution blocks
- Medical device pneumatic control units
- Semiconductor handling equipment
Installation guidelines:
Apply 0.2-0.5Nm torque during assembly. Use thread sealant only on male threads,
avoiding contact with port openings. Maximum angular misalignment tolerance: ±3°.
| Property | Property Value |
|---|---|
| sku | X-APZR604 |
