Airtac X-EPE Fitting - T-Type Tee X-EPE12
AirTAC X-EPE12 T-Type Tee Fitting Technical Details
- Model: X-EPE12-T
- Type: Push-in T-port pneumatic connector
- Material: Nickel-plated brass (base), NBR seals
- Thread standard: PT1/8 (BSPP) female threads
- Tube compatibility: Ø4mm (5/32") or Ø6mm (1/4") OD pneumatic tubing
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Leakage rate: <0.1 mL/min @ 0.5 MPa
- Vibration resistance: 10-55Hz @ 1.5mm amplitude
- Weight: 28g ±0.5g
- Dimensions: 18mm (L) × 12mm (W) × 12mm (H) body size
- Port spacing: 10mm center-to-center between outlets
- Certifications: RoHS compliant, ISO 6150-B standard
Precision-machined T-connector featuring tool-free tube installation with color-coded release rings (gray for 4mm, black for 6mm). Anti-vibration teeth ensure secure tube retention, while the nickel plating provides corrosion resistance in humid environments. Designed for 3-way airflow distribution with minimal pressure drop.
- Branching pneumatic circuits in automation equipment
- Modular assembly systems requiring compact flow division
- Vacuum line distribution in packaging machinery
- Medical device gas line connections
- Educational robotics pneumatic systems
Installation protocol:
Cut tubing ends square with dedicated cutter, insert fully until "click".
For high-vibration environments, apply 0.6-0.8Nm torque to threaded ports.
Replace seals every 5 years or 100,000 cycles.
| Property | Property Value |
|---|---|
| sku | X-EPE12 |
