Airtac X-EPEG Adapter - T-Type Reducing Tee X-EPEG64
AirTAC X-EPEG64 T-Type Reducing Tee Fitting Detailed Specifications
- Model: X-EPEG64
- Type: T-Type Reducing Tee (Male Threads)
- Material: Nickel-plated brass body + POM (Polyoxymethylene) seal
- Primary Port Size: G1/8 (R1/8)
- Reduced Port Size: G1/4 (R1/4)
- Max Working Pressure: 1.5 MPa (15 bar)
- Burst Pressure: ≥4.5 MPa
- Temperature Range: -5℃ to 80℃ (with NBR seals)
- Weight: 88±2g
- Dimensions: 38mm (L) × 28mm (W) × 38mm (H)
- Thread Standard: ISO 228 (BSPP)
- Surface Roughness: Ra ≤3.2μm
- Vibration Resistance: 10-60Hz, 1.5mm amplitude
Precision-engineered flow distribution component with asymmetric pressure compensation, featuring corrosion-resistant nickel plating and zero-leak O-ring seals. The tapered thread design (R-series) ensures secure connections in high-vibration environments. Compatible with ISO 15407-1 standard pneumatic systems.
- Branch line creation in compact pneumatic manifolds
- Pressure gauge installation points on machinery
- Modular assembly in automated packaging lines
- Coolant line distribution in CNC equipment
- Vacuum system plumbing for semiconductor tools
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads (do not over-tighten beyond 1.5Nm torque).
Ensure flow arrow direction matches main pipeline orientation. Post-installation pressure
test required at 1.8MPa for 5 minutes.
| Property | Property Value |
|---|---|
| sku | X-EPEG64 |
