Airtac X-EPG Connector - Reducing Straight X-EPG1210
AirTAC X-EPG1210 Reducer Straight Connector Specifications
- Model: X-EPG1210
- Type: Double ferrule reducer union
- Material: Brass with nickel plating (CuZn39Pb3)
- Seal material: NBR/FKM optional
- Thread type: Metric (M5×0.8 & M10×1.0)
- Pressure range: 0-1.0 MPa (145 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Tube compatibility: PU/Nylon Φ4mm & Φ6mm
- Surface hardness: ≥HV200
- Weight: 9.5±0.3g
- Dimensions: 21.5mm(L) × 12mm(Ø) × 15.8mm(Hex)
- Torque limit: 1.2-1.5 N·m
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-machined transition fitting for hybrid pneumatic systems, featuring dual O-ring seals and anti-vibration grooves. The stepped design enables secure connection between different tubing sizes while maintaining minimal pressure drop (ΔP≤0.02MPa @ 0.5MPa). Electroless nickel coating provides corrosion resistance in humid environments.
- Branch line reductions in multi-circuit manifolds
- Sensor air supply line transitions
- Robotic gripper tooling air networks
- Compact valve terminal installations
- Medical device pneumatic consoles
Installation protocol:
Hand-tighten until snug before applying final 1/4 turn with wrench.
Maximum 2 reuses recommended. Apply silicone-free lubricant on threads
for high-cycle applications (>50,000 cycles).
| Property | Property Value |
|---|---|
| sku | X-EPG1210 |
