Airtac X-EPH External Hex Elbow Connector X-EPH12M12
$4.31
Regular price
$11.81
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-EPH12M12
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-EPH12M12 Hex Elbow Joint Technical Details
- Model: X-EPH12M12
- Type: External hexagon elbow joint (rotary type)
- Material: Stainless steel body + brass swivel nut
- Thread specification: M12×1.0 male thread
- Max torque resistance: 12 N·m
- Pressure rating: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Surface treatment: Electroless nickel plating
- Rotational angle: 360° continuous rotation
- Leakage rate: ≤3 bubbles/min (under 0.5 MPa)
- IP rating: IP54 (dust/water resistant)
- Weight: 28.5±0.5g
- Dimensions: 32mm(Length) × 19mm(Width) × 24mm(Height)
Precision-engineered pivot joint featuring dual-material construction for corrosion resistance and torque durability. The integrated O-ring (NBR material) ensures leak-free operation even under vibration. Designed with 2mm hexagonal wrench flats for tool-assisted tightening.
Common Implementations:
- Pneumatic arm reorientation in robotic assembly lines
- Modular piping connections for semiconductor fab equipment
- Hydraulic sensor mounting in agricultural machinery
- Coolant line redirection in CNC machining centers
- Packaging machine air nozzle articulation
Installation protocol:
Apply thread sealant (LOCTITE 5452 recommended) before assembly.
Tighten to 8-10 N·m torque using calibrated wrench. Avoid overtightening
beyond 12 N·m to prevent thread deformation. Perform pressure test
at 1.25× working pressure after installation.
| Property | Property Value |
|---|---|
| sku | X-EPH12M12 |
