Airtac X-EPH External Hex Elbow Connector X-EPH12M16
AirTAC X-EPH12M16 Hexagonal Elbow Joint Technical Details
- Model: X-EPH12M16
- Type: Male Thread Hex Elbow (90° bend)
- Thread Specification: M16×1.5 (ISO metric fine)
- Material: Nickel-plated brass (C3604)
- Surface Hardness: ≥HV200
- Working Pressure: 0.05-1.0 MPa
- Proof Pressure: 1.5 MPa
- Burst Pressure: ≥3.0 MPa
- Temperature Range: -5℃ to 80℃ (with NBR seals)
- Hex Size: 19mm across flats
- Seal Type: Embedded O-ring (NBR standard, FKM optional)
- Tube Compatibility: Ø12mm OD pneumatic tubing
- Weight: 28g ±2g
- Dimensions: 46mm (Total L) × 19mm (Hex W) × 26mm (Bend H)
- Thread Engagement: 13mm minimum
- Vibration Resistance: ≤10Hz @ 1.5mm amplitude
Precision-machined elbow connector featuring anti-vibration lock structure and 360° swivel capability. The chromium-free nickel plating ensures RoHS compliance while providing corrosion resistance in humid environments. Includes built-in tube grip teeth for secure pneumatic line retention.
- Compact pneumatic cylinder installations
- Robotic end-effector tooling connections
- Packaging machine rotary union interfaces
- Medical equipment gas line routing
- Automated test bench manifolds
- Food processing machinery (dry environments)
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads. Tighten to 14-16N·m torque using
crowfoot wrench. Avoid overtightening which may deform sealing surface.
Perform pressure test at 1.25× working pressure after installation.
| Property | Property Value |
|---|---|
| sku | X-EPH12M16 |
