Airtac X-EPH External Hex Elbow Connector X-EPH604
AirTAC X-EPH604 Hexagonal Elbow Swivel Joint Specifications
- Model: X-EPH604
- Type: External hexagon swivel elbow joint (male thread)
- Thread specification: M5×0.8 (external)
- Material: Nickel-plated brass body + POM seal
- Tube compatibility: Ø4mm polyurethane/nylon tubing
- Max torque resistance: 2.5 N·m
- Pressure range: 0-1.0 MPa (145 psi)
- Temperature range: -20℃ to 80℃ (continuous use)
- Swivel angle: 360° free rotation
- Weight: 28±2g
- Dimensions: 25mm(L) × 16mm(W) × 16mm(H)
- Surface hardness: HV200-250 (nickel plating)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Certification: RoHS compliant
Precision-machined swivel joint featuring a corrosion-resistant nickel layer and anti-vibration POM sealing ring. The 45° elbow design enables flexible tubing routing in confined spaces while maintaining leak-free performance under dynamic motion. Includes integrated O-ring groove for positive locking.
- Robotic arm pneumatic tool changers
- CNC machine coolant line connections
- Semiconductor wafer handling equipment
- Mobile hydraulic test benches
- Food processing pneumatic actuators
Installation protocol:
Use 8mm open-end wrench on hex flats during assembly.
Apply 1.2-1.8 N·m torque with thread seal tape (PTFE recommended).
Perform 5 full swivel rotations post-installation to seat seals.
| Property | Property Value |
|---|---|
| sku | X-EPH604 |
