Airtac X-EPHW Adapter - F-Type Thread Swivel Tee X-EPHW802
$7.46
Regular price
$14.96
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-EPHW802
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-EPHW802 F-Type Threaded Swivel Tee Fitting Specifications
- Model: X-EPHW802
- Type: F-type (BSPP) threaded swivel tee
- Material: Brass with nickel-plated surface
- Thread standard: G1/8 (ISO228-1 compliant)
- Operating pressure: 0.3-1.5 MPa
- Proof pressure: 2.25 MPa
- Burst pressure: ≥3 MPa
- Temperature range: -5℃ to 80℃
- Port configuration: Three-way (1 inlet, 2 outlets)
- Seal material: NBR (Nitrile) rubber
- Rotational torque: ≤0.3 N·m
- Weight: 82±3g
- Dimensions: 45mm(L) × 25mm(W) × 25mm(H)
- Surface roughness: Ra ≤3.2μm
- Vibration resistance: 10-55Hz, 1.5mm amplitude
High-precision flow distribution fitting with 360° rotatable ports for flexible piping alignment. Features triple-seal construction with anti-vibration locking nuts, designed for leak-free performance in dynamic pneumatic systems. Compatible with ISO 15407-1 compliant tubing.
Typical Applications:
- Modular pneumatic circuit branching
- Robotic arm tool changer systems
- CNC machine air distribution networks
- Plastic injection molding machine air lines
- Semiconductor manufacturing equipment
Installation note:
Apply thread sealant only on male threads (tapered ends).
Rotate female ports clockwise until resistance is felt, then tighten 1/4 turn with 12mm wrench.
Avoid overtightening beyond 5 N·m torque.
| Property | Property Value |
|---|---|
| sku | X-EPHW802 |
