Airtac X-EPKD Adapter - Reducing Thread Manifold X-EPKD8602
AirTAC X-EPKD8602 Reducing Thread Five-Way Fitting Specifications
- Model: X-EPKD8602
- Type: Pneumatic manifold with stepped thread ports
- Material: Brass with Nickel Plating (surface hardness ≥HV200)
- Main port thread: PT1/2 (G1/2)
- Branch ports: 4×PT3/8 (G3/8) reducing threads
- Pressure rating: 0.05-1.0 MPa
- Temperature range: -5℃ to 80℃ (no ice formation)
- Weight: 280±10g
- Dimensions: 76mm(L) × 50mm(W) × 38mm(H)
- Surface roughness: Ra ≤1.6μm (sealing areas)
- Leakage rate: ≤3 bubbles/min (under 0.5MPa air pressure)
- Certification: RoHS compliant
High-density flow distribution block featuring asymmetrical port sizing for pressure/flow optimization. The electroplated surface resists corrosion in humid environments while maintaining solid grounding continuity (≤0.1Ω resistance between ports). Designed for vibration-prone installations with anti-loosening thread design.
- Multi-cylinder synchronization circuits in stamping machines
- Modular pneumatic control stations (ISO 5599-1 compatible)
- Air preparation unit manifolds with pressure regulators
- Robotic arm tool changer pneumatic distribution
- Textile machinery air flow distribution systems
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads (clockwise winding).
Avoid overtightening beyond 15N·m torque to prevent port deformation.
Recommended maintenance: Annual inspection for microcracks using dye penetrant testing.
| Property | Property Value |
|---|---|
| sku | X-EPKD8602 |
