Airtac X-EPKG Reducing Five-Way Fitting X-EPKG86
AirTAC X-EPKG86 Reducing Five-Way Fitting Specifications
- Model: X-EPKG86
- Type: Reducing Five-Way Fitting (Pneumatic Manifold)
- Primary port size: PT1/2 (G1/2)
- Reduced port size: PT1/4 (G1/4)
- Material: Anodized aluminum alloy (AL6063-T5)
- Surface treatment: Chromate conversion coating
- Max working pressure: 1.0 MPa
- Temperature range: -20℃ to 80℃
- Weight: 278g ±5g
- Dimensions: 86mm(L) × 60mm(W) × 34mm(H)
- Thread standard: ISO 228 (G-series parallel threads)
- Seal type: Integrated O-ring groove (NBR seals pre-installed)
- Flow capacity: 750 L/min (ANR)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Compliance: RoHS compliant
Multi-functional manifold block engineered for compact pneumatic systems requiring flow distribution with pressure drop optimization. Features asymmetrical port sizing (1/2" main flow path with 1/4" control ports) to balance flow dynamics and space constraints. The anodized surface provides enhanced corrosion resistance for humid environments.
- Modular pneumatic control panels
- Robotic end-effector air distribution
- CNC machine tool clamping systems
- Plastic injection molding machine manifolds
- Automated packaging line air circuits
Installation guidelines:
Apply thread sealant only on male threads (Loctite 545 recommended).
Tighten to 14-16 N·m torque using flank-contact wrench.
Avoid axial stress on ports during plumbing assembly.
Critical note:
Not compatible with phosphate ester fluids or chlorinated solvents.
Maximum instantaneous pressure spikes should not exceed 1.5 MPa.
