Airtac X-EPU Connector - Straight X-EPU10
AirTAC X-EPU10 Straight Threaded Connector Technical Details
- Model: X-EPU10
- Type: Straight-through pneumatic fitting (male thread to male thread)
- Thread specification: G1/8 (ISO228-1 compliant)
- Material: Brass with nickel plating (CuZn39Pb3)
- Max working pressure: 1.5 MPa (15 bar)
- Temperature range: -20℃ to 120℃
- Seal type: Integrated O-ring (NBR rubber)
- Weight: 12g ±0.5g
- Dimensions: 18mm(L) × 10mm(Dia.) × 18mm(H)
- Surface roughness: Ra ≤1.6μm
- Certifications: RoHS compliant, ISO 1179-1 standard
- Vibration resistance: 10-2000Hz, 20m/s²
- IP rating: IP40 (protected against tool access)
Precision-machined connector featuring dual-purpose threads (BSPP parallel) with anti-vibration grooves. The electroless nickel coating provides enhanced corrosion resistance exceeding 96hrs salt spray test. Optimized flow path reduces turbulence with a 0.8mm minimum inner diameter, achieving Cv=0.12 flow coefficient.
- Modular pneumatic system interconnections
- Sensor mounting interfaces in robotic arms
- Medical gas line distribution panels
- Compressed air instrumentation ports
- Vacuum circuit junctions
Installation guidelines:
Apply 0.5-0.8Nm torque during assembly. Use PTFE tape only on male threads,
ensuring 1.5-2 thread turns remain exposed. Avoid overtightening beyond 1.2Nm
to prevent housing deformation. For vibration-prone environments, apply
thread-locking compound to the first two threads.
| Property | Property Value |
|---|---|
| sku | X-EPU10 |
