Airtac X-EPU Connector - Straight X-EPU16
AirTAC X-EPU16 Straight Through Push-in Fitting Technical Details
- Model: X-EPU16
- Type: Straight-through pneumatic connector
- Body material: Nickel-plated brass (ISO 1179 compliant)
- Seal material: NBR (Nitrile rubber)
- Port size: G1/8 (ISO 228-1 standard)
- Operating pressure: 0.05–1.0 MPa
- Burst pressure: ≥3.0 MPa
- Temperature range: -5℃ to 80℃
- Tube compatibility: Ø4mm, Ø6mm, Ø8mm (PU/Nylon)
- Thread engagement: 6 full turns minimum
- Leakage rate: ≤0.3 NL/min @ 0.5 MPa
- Weight: 0.12kg ±5%
- Dimensions: 55mm(L) × 16mm(Ø) × 16mm(port spacing)
- Vibration resistance: 10-55Hz @ 1.5mm amplitude
- Certification: RoHS compliant
- Protection rating: IP40
Precision-engineered push-to-connect fitting featuring dual-stage sealing (O-ring + collet grip) for zero-leak performance in dynamic pneumatic systems. The 360° rotatable collar enables tool-free tube installation and removal, while the corrosion-resistant nickel plating ensures durability in humid environments.
- Modular pneumatic circuit assembly lines
- Robotic arm end-effector air supply connections
- Medical device gas delivery systems
- Packaging machine actuator networks
- Laboratory analytical instrument pneumatics
- Semiconductor cleanroom equipment
Installation protocol:
Cut tubes square (max 0.5° angle tolerance), deburr thoroughly, and insert until
audible click. For high-vibration environments, apply thread lock adhesive
to port connections. Maximum recommended reconnection cycles: 50 times.
| Property | Property Value |
|---|---|
| sku | X-EPU16 |
