Airtac 2KWX Fluid Solenoid Valve 2KWX05010B
2. Wide pressure range adaptability – options include Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Compact structure with minimized footprint, lightweight design, and tool-free assembly/disassembly capability;
4. Brass valve body construction with Class B thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon consultation with our technical department;
5. IP65-rated coil protection, available in direct lead wire or DIN connector wiring configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWX Series
AirTAC 2KWX05010B Fluid Solenoid Valve Technical Details
- Model: 2KWX05010B
- Type: Direct-acting 2-way normally closed (2/2 NC)
- Port size: G1/8 (ISO228 standard)
- Thread type: Parallel (BSPP)
- Operating pressure: 0.02–1.0 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC24V (±10%), AC110V (±15%), AC220V (±15%)
- Fluid compatibility: Water, light oils, air (lubricated or non-lubricated)
- Temperature range: -5℃ to 80℃ (fluid/media dependent)
- Seal material: NBR (standard), optional FKM for chemical resistance
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Power consumption: 2.5W (DC), 3.2VA (AC)
- Protection rating: IP65 (coil assembly)
- Housing material: Brass CW617N (lead-free compliant)
- Weight: 320g ±5% (including coil)
- Dimensions: 85mm(L) × 35mm(W) × 60mm(H)
- Orifice diameter: 2.5mm
- Max flow rate: 25 L/min (water at 0.5MPa)
- Viscosity range: ≤21 cSt
High-flow fluid control valve with corrosion-resistant brass body and multi-voltage compatibility. Features manual override capability via push-button actuator and bubble-tight shutoff design. The coil is vacuum-encapsulated for moisture protection, with DIN43650A connector standard. Suitable for intermittent or continuous duty cycles.
- Industrial water cooling circuits
- Beverage dispensing/filling lines
- Hydroponic nutrient delivery systems
- Medical equipment sterilization cycles
- CNC machine coolant control
- Automotive test bench fluid simulation
Installation guidelines:
Mount in any orientation except coil-down position. Install 100μm filter upstream.
For viscous fluids, maintain ambient temperature ≥5℃. Cycle rate should not exceed 1200 operations/hour.
| Property | Property Value |
|---|---|
| sku | 2KWX05010B |
| Port Size | PT3/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | DC24V |
