Airtac SAI32 Standard Cylinder SAI32AX10
The AirTAC SAI32 Standard Cylinder SAI32AX10 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø32mm bore and 10mm stroke, G1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ32 mm
- Stroke10 mm
- Port sizeG1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAI32 Standard Cylinder SAI32AX10
The AirTAC SAI32X10 is a double-acting ISO 15552 profile cylinder engineered for ultra-short motion control. Operating at 0.5 MPa, it generates 402 N of push force and 345 N of pull force. The 10 mm stroke is a made-to-order specification tailored for compact clamping and ejection tasks where standard 25 mm strokes would be too long.
This model features a SUS420J2 stainless steel rod (option A) for enhanced durability against moisture and minor corrosion. It uses PT tapered port threads and includes adjustable air cushions at both ends to soften impact, though cushion effectiveness is limited at this extremely short 10 mm distance.
Airtac SAI32 Standard Cylinder SAI32AX10 Technical Specifications
| Model | Airtac SAI32 Standard Cylinder SAI32AX10 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 10 mm |
| Acting type | Double acting |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI32 Standard Cylinder SAI32AX10
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 32 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI32 Standard Cylinder SAI32AX10 Is Used
Short-Stroke Clamping
Ideal for holding small electronic components or workpieces securely in fixtures where only a few millimeters of travel are required.
Part Ejection
Provides a rapid 10 mm push to eject finished parts from an assembly line without extending into the main conveyor path.
Valve Actuation
Suitable for mechanically triggering pneumatic or mechanical valves in compact machinery where space is strictly limited.
Is the Airtac SAI32 Standard Cylinder SAI32AX10 the Right Cylinder?
Select this 32 mm bore actuator when a project requires precise point-to-point movement in a very tight footprint, as the 10 mm stroke prevents overtravel damage. If an application needs greater thrust, stepping up to the 40 mm bore yields 628 N of push force at 0.5 MPa.
Because the 10 mm stroke is non-standard, ensure your machined mating surfaces perfectly match the ISO 15552 mounting interface. For tasks requiring the piston to hold its position during a compressed air loss, note that a standard SAI cylinder will drift; consider the SAIL variant with an air-released lock or an external pilot-operated check valve.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI32 Standard Cylinder SAI32AX10 FAQ
At an operating pressure of 0.5 MPa, the SAI32X10 provides 402 N of push force and 345 N of pull force. At 0.7 MPa, the push force increases to 563 N.
Yes, the SAI32X10 is dimensionally interchangeable per ISO 15552 standards. It serves as a direct replacement for other ISO 15552 profile cylinders of the same bore size, provided the 10 mm made-to-order stroke fits your design.
