Airtac SAI32 Standard Cylinder SAI32AX100
The AirTAC SAI32 Standard Cylinder SAI32AX100 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø32mm bore and 100mm stroke, G1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ32 mm
- Stroke100 mm
- Port sizeG1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAI32 Standard Cylinder SAI32AX100
The AirTAC SAI32X100 is a double-acting ISO 15552 profile cylinder engineered for standardized automation. Delivering 402 N of push force at 0.5 MPa, it provides precise linear motion for compact assemblies. The extruded aluminum barrel eliminates tie-rods, ensuring a clean exterior that integrates seamlessly into modern machine frames.
Configured with a SUS420J2 stainless steel rod (material code A), this unit offers superior corrosion resistance compared to standard carbon steel. It utilizes PT tapered port threads for a reliable, leak-free pneumatic connection. The barrel features integrated sensor grooves on both sides, allowing for flexible mounting of CMSE or DMSE switches when position feedback is required.
Airtac SAI32 Standard Cylinder SAI32AX100 Technical Specifications
| Model | Airtac SAI32 Standard Cylinder SAI32AX100 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI32 Standard Cylinder SAI32AX100
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 32 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI32 Standard Cylinder SAI32AX100 Is Used
Small Part Ejection
Ideal for pushing small molded parts out of machining fixtures with precise 100 mm travel.
Package Diverting
Provides reliable actuation for lightweight diverter arms on packaging conveyor lines.
Clamp Operations
Suitable for low-force clamping tasks in secondary woodworking or plastic assembly processes.
Is the Airtac SAI32 Standard Cylinder SAI32AX100 the Right Cylinder?
Providing 345 N of pull force at 0.5 MPa, this 32 mm bore is optimal for light-duty handling. If your application requires greater thrust, stepping up to the 40 mm bore yields 628 N of push force at the same pressure. For this 100 mm stroke, side-load risks are minimal, but always ensure axial alignment to prevent premature rod-bearing wear.
As a dimensionally interchangeable ISO 15552 cylinder, it serves as a direct replacement for other standard profile cylinders. Ensure your setup matches the PT G1/8 port and utilize FA or LB mounting accessories. Note that this standard cylinder does not hold loads upon air loss; for position holding, consider the SAIL variant.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI32 Standard Cylinder SAI32AX100 FAQ
The SAI32X100 generates 402 N of push force and 345 N of pull force at 0.5 MPa, reaching a maximum theoretical force of 82 kgf at 1.0 MPa.
Yes, the SAI32X100 is a genuine ISO 15552 profile cylinder, making it dimensionally interchangeable as a direct replacement for other standard ISO 15552 cylinders with matching 32 mm bores.
