Airtac SAI32 Standard Cylinder SAI32AX110
The AirTAC SAI32 Standard Cylinder SAI32AX110 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø32mm bore and 110mm stroke, G1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ32 mm
- Stroke110 mm
- Port sizeG1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAI32 Standard Cylinder SAI32AX110
The AirTAC SAI32X110 is a double-acting ISO 15552 profile cylinder engineered for compact automation. Delivering a push force of 563 N at 0.7 MPa, this 32 mm bore unit is tailored for precise 110 mm stroke tasks. Its extruded aluminum barrel eliminates tie-rods, providing a sleek yet rigid structure that drops directly into standardized ISO 15552 mounting footprints.
This specific configuration features a SUS420J2 stainless steel piston rod (material code A) for enhanced corrosion resistance compared to standard carbon steel. It utilizes PT tapered port threads and lacks a standard magnet, meaning position sensing via CMSE or DMSE switches is not supported unless specified otherwise. For applications requiring dual-end locking, the related SAIL variant offers an integrated air-released brake.
Airtac SAI32 Standard Cylinder SAI32AX110 Technical Specifications
| Model | Airtac SAI32 Standard Cylinder SAI32AX110 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 110 mm |
| Acting type | Double acting |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI32 Standard Cylinder SAI32AX110
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 32 | Bore size in mm. |
| ×110 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI32 Standard Cylinder SAI32AX110 Is Used
Small Parts Clamping
Ideal for holding lightweight aluminum or plastic components during machining, providing 563 N of reliable clamping force at 0.7 MPa.
Package Diverting
Extends 110 mm to push small cartons off a main conveyor line, utilizing the compact 32 mm profile to fit within tight transfer stations.
Gate Actuation
Operates small access doors or machine guards, where the SUS420J2 stainless rod offers dependable resistance against minor environmental moisture.
Is the Airtac SAI32 Standard Cylinder SAI32AX110 the Right Cylinder?
Selecting this 32 mm bore is optimal when your application requires 563 N of thrust at 0.7 MPa, bridging the gap between smaller actuators and the 40 mm bore which outputs 879 N. If your system demands less force, stepping down to a 25 mm equivalent reduces physical size, though the SAI series starts at 32 mm. The 110 mm stroke provides ample extension for mid-range positioning without the severe side-load risks inherent to longer strokes.
Because this is a standard double-acting cylinder, it will not maintain its position if air pressure drops completely; the piston and load will drift. For gravity-dependent loads that must be held securely during exhaust or emergency stops, specify the SAIL locking version or integrate an external pilot-operated check valve. When replacing existing actuators, verify the PT G1/8 port, mounting accessories like FA flanges, and the 110 mm stroke length.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI32 Standard Cylinder SAI32AX110 FAQ
At a standard operating pressure of 0.7 MPa, this 32 mm bore cylinder provides a push force of 563 N and a pull force of 345 N. The theoretical maximum force at 1.0 MPa is 82 kgf.
Yes, the SAI32X110 is dimensionally interchangeable per ISO 15552. You can drop it into existing ISO 15552 mounting interfaces, provided you match the G1/8 port and 110 mm stroke.
