Airtac SAI32 Standard Cylinder SAI32AX115
2. Asymmetrical bidirectional sealing structure for piston with integrated oil reservoir, ensuring compact dimensions;
3. Mesh-reinforced aluminum tube construction without tie rods, excellent corrosion resistance. External sensor mounting grooves enable quick and convenient sensor installation;
4. Smooth cushioning adjustment mechanism;
5. Multiple cylinder configurations and mounting accessories available for customer customization;
6. High-temperature resistant sealing materials compatible with operating temperature range of 0~150℃.
Category: Standard Cylinders , Brand: AirTAC , Series: SAI32
AirTAC SAI32 Standard Cylinder SAI32AX115 Technical Specifications
- Model: SAI32AX115
- Bore size: 32 mm
- Stroke: 115 mm
- Action type: Double-acting
- Mounting style: Front flange (AX series)
- Operating pressure: 0.15–0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Temperature range: -20℃ to 80℃
- Seal material: NBR (Nitrile Butadiene Rubber)
- Port size: 1/4" NPT (G1/8 optional)
- Piston speed: 50–800 mm/s
- Rod thread: M12×1.25
- Weight: 1.45 kg (bare cylinder), 1.68 kg (with magnetic switch)
- Dimensions:
- Body diameter: 32 mm ±0.1
- Total length (L): 253 mm (including rod and mounts)
- Stroke tolerance: +2.0 mm
- Mounting hole spacing: 25 mm (center-to-center)
The SAI32AX115 features a chromium-plated piston rod with hardened steel construction, providing exceptional wear resistance in high-cycle applications. Its integrated cushioning mechanism reduces impact noise by 15dB compared to basic models. The cylinder body uses aerospace-grade aluminum alloy with oxidation-resistant coating, suitable for humid environments. Includes built-in magnet for sensor compatibility.
- Automated assembly line clamping mechanisms
- CNC machine tool door interlocks
- Packaging machine pusher arms
- Textile machinery tension control systems
- Automotive welding fixture positioning
Installation guidelines:
Lubricate with ISO VG32 hydraulic oil before initial operation.
Maintain 0.5mm minimum clearance between magnetic switch and cylinder body.
For vertical mounting, install with piston rod facing downward to prevent seal wear.
- Theoretical force output: 245N (at 0.6MPa)
- Max lateral load capacity: 15N
- Service life: 5,000 km (ISO 15552 standard)
- Re-pressurization response time: ≤0.3s
| Property | Property Value |
|---|---|
| sku | SAI32AX115 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Piston Rod Material | SUS420J2 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 115mm |
