Airtac ACEJ12 Adjustable Compact Cylinder ACEJ12X40-40
The AirTAC Airtac ACEJ12 Adjustable Compact Cylinder ACEJ12X40-40 is a genuine double acting, adjustable stroke ISO 21287 compact air cylinder with a Ø12mm bore and 40mm stroke, M5×0.8 air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ12 mm
- Stroke40 mm
- Port sizeM5×0.8
- Acting typeDouble acting, adjustable stroke
- Rod threadM3×0.5
- CushionFixed TPU bumper (both ends)
About the Airtac ACEJ12 Adjustable Compact Cylinder ACEJ12X40-40
This compact ISO 21287 cylinder is double acting, with air powering both the extend and retract strokes. A 12 mm bore delivers 56.5 N push and 42.4 N pull at 0.5 MPa, rising to 79.2 N at 0.7 MPa, and the -40 code gives a 40 mm adjustment window: an external stop screw trims the extend stroke anywhere from 0 to 40 mm on site, no disassembly needed.
The short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it slots into slim fixtures and guarding where a full-length body will not fit. In practice, plan for roughly 34 N of usable push at 0.5 MPa, which lifts about 3 kg vertically with a 2:1 margin. A fixed TPU bumper at each end absorbs end-of-stroke shock, and FA flange or LB foot mounts bolt straight to the ISO 21287 face.
Airtac ACEJ12 Adjustable Compact Cylinder ACEJ12X40-40 Technical Specifications
| Model | Airtac ACEJ12 Adjustable Compact Cylinder ACEJ12X40-40 |
|---|---|
| Series | ACEJ compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø12 mm |
| Stroke | 40 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | M5×0.8 |
| Rod thread | M3×0.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 50 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø12mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 57 N | 42 N |
| 0.7 MPa | 79 N | 59 N |
| Max (@1.0 MPa) | 12 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac ACEJ12 Adjustable Compact Cylinder ACEJ12X40-40
| ACEJ | ISO 21287 compact cylinder (adjustable-stroke). |
|---|---|
| 12 | Bore size in mm. |
| ×40 | Stroke length in mm. |
| -40 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACEJ12 Adjustable Compact Cylinder ACEJ12X40-40 Is Used
Micro jig clamping
The 34 N usable push at 0.5 MPa clamps small brackets or PCB fixtures on assembly jigs, with the 0-40 mm window set to the part height.
Small-part ejection
Ejects pins, springs or stamped parts from a die or bowl-feed track; the short body fits inside the die shoe where longer cylinders cannot.
Compact gate pusher
Pushes small lids or trays off a conveyor lane; order the -S magnet version if CMSE / DMSE end-position sensing is added later.
Is the Airtac ACEJ12 Adjustable Compact Cylinder ACEJ12X40-40 the Right Cylinder?
At 56.5 N push (0.5 MPa) this bore 12 unit suits light clamping, sorting and small-part ejection; step up to bore 16 (100.5 N) or bore 20 (157.1 N) for heavier work. The stop screw only shortens the extend stroke - it is not a mid-stroke lock, so the rod still drifts if air is lost. Choose the -S code if you later need CMSE / DMSE switch sensing; this version has no magnet fitted. Female M3x0.5 rod thread, M5x0.8 ports, PT body ports.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACEJ12 Adjustable Compact Cylinder ACEJ12X40-40 FAQ
Push is 56.5 N and pull 42.4 N at 0.5 MPa; at 0.7 MPa push is 79.2 N and pull 59.4 N, with a theoretical maximum of 11.5 kgf at 1.0 MPa. It runs on air filtered to 40 um at 0.15-1.0 MPa (22-145 psi), proof pressure 1.5 MPa (215 psi), speed 30-500 mm/s, temperature -20 to +70 C. The extend stroke is trimmed by the external stop screw anywhere within the 40 mm window, and the rod end is female M3x0.5 with M5x0.8 ports.
The ISO 21287 short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, with a hard-anodized aluminium body, S45C hard-chrome rod and fixed TPU bumpers at both ends. This version has no magnet; the optional -S code adds one so CMSE / DMSE switches can be mounted. FA flange and LB foot brackets bolt directly to the ISO 21287 mounting face.
