Airtac ACEJ12 Adjustable Compact Cylinder ACEJ12X45-30
The AirTAC Airtac ACEJ12 Adjustable Compact Cylinder ACEJ12X45-30 is a genuine double acting, adjustable stroke ISO 21287 compact air cylinder with a Ø12mm bore and 45mm stroke, M5×0.8 air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ12 mm
- Stroke45 mm
- Port sizeM5×0.8
- Acting typeDouble acting, adjustable stroke
- Rod threadM3×0.5
- CushionFixed TPU bumper (both ends)
About the Airtac ACEJ12 Adjustable Compact Cylinder ACEJ12X45-30
The ACEJ12X45-30 is a double acting ISO 21287 compact cylinder with an adjustable extend stroke: an external stop screw trims the 45 mm stroke by up to 30 mm on site, giving a usable range of 15-45 mm without changing the cylinder. At 0.5 MPa the 12 mm bore delivers 56.5 N push and 42.4 N pull, rising to 79.2 N push at 0.7 MPa. Running on air filtered to 40 um at 0.15-1.0 MPa (22-145 psi), it moves at 30-500 mm/s.
The short ISO 21287 body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it slots into slim fixtures, small guarding panels and bench-top rigs. A fixed TPU bumper at each end absorbs end-of-stroke impact, the hard-anodized aluminium body carries a hard-chrome S45C rod, and the female M3x0.5 rod thread accepts standard tooling plates. As a rule of thumb, plan on roughly 34 N of real work at 0.5 MPa, which lifts about 2.9 kg vertically with a 2:1 margin. Note: this model has no magnet fitted; order the -S code if you need CMSE / DMSE switch sensing.
Airtac ACEJ12 Adjustable Compact Cylinder ACEJ12X45-30 Technical Specifications
| Model | Airtac ACEJ12 Adjustable Compact Cylinder ACEJ12X45-30 |
|---|---|
| Series | ACEJ compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø12 mm |
| Stroke | 45 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | M5×0.8 |
| Rod thread | M3×0.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 50 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø12mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 57 N | 42 N |
| 0.7 MPa | 79 N | 59 N |
| Max (@1.0 MPa) | 12 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac ACEJ12 Adjustable Compact Cylinder ACEJ12X45-30
| ACEJ | ISO 21287 compact cylinder (adjustable-stroke). |
|---|---|
| 12 | Bore size in mm. |
| ×45 | Stroke length in mm. |
| -30 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACEJ12 Adjustable Compact Cylinder ACEJ12X45-30 Is Used
Micro part ejection
Ejects small machined pins or moulded inserts from a fixture, with the 15-45 mm range set so the rod never over-travels into the die face.
Lab slide actuation
Pushes a 2-3 kg sample tray along a compact bench-top slide where the short body fits under a low cover.
Small carton push-off
Knocks single blister cards off a conveyor lane; the TPU bumper quiets the end of each 45 mm stroke.
Is the Airtac ACEJ12 Adjustable Compact Cylinder ACEJ12X45-30 the Right Cylinder?
Size check: the next bore up, ACEJ 16 mm, gives 100.5 N push at 0.5 MPa, while this 12 mm bore covers light clamping and positioning at 56.5 N push / 42.4 N pull. If your stroke must be set exactly at the machine rather than ordered fixed, the 30 mm window here beats a fixed-stroke ACE. Mounting: FA flange or LB foot brackets bolt to the ISO 21287 face, with I and Y rod knuckles on the M3x0.5 female thread. Remember the stop screw is a mechanical end stop only - it does not hold a load if air is lost.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACEJ12 Adjustable Compact Cylinder ACEJ12X45-30 FAQ
Push 56.5 N and pull 42.4 N at 0.5 MPa; push 79.2 N and pull 59.4 N at 0.7 MPa; theoretical maximum 11.5 kgf at 1.0 MPa. It is double acting with a 30 mm adjustment window on the 45 mm stroke (usable 15-45 mm), M5x0.8 ports, PT thread, female M3x0.5 rod thread, 0.15-1.0 MPa (22-145 psi) operating pressure, 1.5 MPa (215 psi) proof pressure, -20 to +70 C, and 30-500 mm/s speed.
The ISO 21287 short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, with a fixed TPU bumper at both ends and FA/LB mounting options. Sensing is not included on this model: the magnet is the optional -S code, so order ACEJ12X45-30S if you want CMSE or DMSE switches to detect rod position.
