Airtac F-TMIC Separate Guide Bracket F-TMICL25X150
2. Slide Bearing Configuration: Suitable for applications requiring radial load resistance in cylinder operations such as braking, offering enhanced torsional rigidity. Linear Bearing Configuration: Ideal for push-pull cylinder motions, high-precision/high-load scenarios, and applications demanding low-friction movement;
3. Proprietary guide unit body design enables multi-directional mounting configurations for flexible installation.
Category: Guide Units , Brand: AIRTAC , Series: F-TMIC
AirTAC F-TMICL25X150 Individual Guide Bracket Technical Details
- Model: F-TMICL25X150
- Type: Linear motion guide system component
- Material: Hardened carbon steel (SCM435 equivalent)
- Surface treatment: Black oxide coating (5-8μm)
- Precision grade: Advanced (C3 clearance class)
- Load capacity:
- Static load (C0): 12.5kN
- Dynamic load (C): 6.8kN
- Dimensions: 150mm(L) × 25mm(W) × 25mm(H)
- Weight: 1.45kg ±2%
- Mounting hole spacing: 120mm (center-to-center)
- Operating temperature: -20℃ to 120℃
- Hardness: 58-62 HRC
- Surface roughness: Ra 0.4μm (sliding surfaces)
- Wear resistance: ≤0.01mm/100km travel
Precision-engineered linear guide component with chromium-molybdenum alloy construction, designed for high-rigidity applications requiring minimal deflection. Features anti-corrosion treatment and pre-loaded ball bearings for smooth reciprocating motion. Compatible with ISO 10285 standard guide rails.
- High-speed CNC router Z-axis stabilization
- Automated optical inspection (AOI) equipment
- Semiconductor wafer handling robots
- Precision injection molding ejector systems
- Laser cutting machine linear actuators
Installation protocol:
Requires torque-controlled mounting (8.8-grade bolts at 12-15Nm) with
parallelism tolerance <0.02mm/m. Lubricate with ISO VG32-grade grease
before initial operation. Periodic re-alignment recommended every
5,000 operational hours.
| Property | Property Value |
|---|---|
| sku | F-TMICL25X150 |
| Bore Diameter | <25 mm> |
| Bearing Category | Linear Bearing |
