Airtac F-TMIL Guide Unit Assembly F-TMIL12X150
2. Sliding bushings: Ideal for applications requiring radial load resistance such as braking operations, offering enhanced torsional rigidity; Linear bushings: Suitable for pushing/lifting actions, high-precision scenarios, and heavy-load applications, particularly optimized for low-friction movement requirements;
3. Specially engineered guide unit body enables multi-directional mounting configurations for flexible installation.
Category: Guide Units | Brand: AirTAC | Series: F-TMIL
AirTAC F-TMIL12X150 Linear Guide Bracket Kit Specifications
- Model: F-TMIL12X150
- Type: Precision linear motion guide assembly
- Shaft diameter: 12mm (hardened chromium-plated steel)
- Stroke length: 150mm ±0.5mm
- Max load capacity: 1,200N (static), 800N (dynamic)
- Bearing type: High-precision ball bushings (4-row design)
- Mounting base material: Aluminum alloy 6063-T5
- Surface treatment: Anodized (black) with corrosion resistance
- Precision grade: C7 class (±50μm/300mm)
- Operating temperature: -20℃ to 80℃
- Lubrication: Pre-lubricated with Molykote EM-30L grease
- Sealing: Integrated wiper seals (NBR material)
- Weight: 850g ±3%
- Dimensions: 200mm(L) × 25mm(W) × 30mm(H)
Complete linear motion solution combining hardened shaft and precision ball bushings, designed for smooth reciprocating movements in industrial automation. Features anti-corrosion treatment and dust-resistant seals for harsh environments. Includes pre-assembled mounting brackets and alignment shims for simplified installation.
- Pick-and-place robot end effectors
- Semiconductor wafer handling systems
- Medical device assembly lines
- CNC tool changer mechanisms
- Automated packaging machinery guides
- 3D printer Z-axis stabilization
Installation note:
Ensure parallel alignment within 0.05mm/m tolerance during mounting.
Apply supplemental lubrication every 500km of travel in high-usage scenarios.
Avoid lateral impact during operation to maintain bearing accuracy.
| Property | Property Value |
|---|---|
| sku | F-TMIL12X150 |
| Bore Diameter | 12mm |
| Stroke | 150mm |
