Airtac F-TMIL Guide Unit Assembly F-TMIL12X200
2. Sliding bushings: Ideal for applications requiring radial load resistance such as braking operations, offering enhanced torsional rigidity; Linear bushings: Suitable for pushing/lifting actions, high-precision scenarios, and heavy-load applications, particularly optimized for low-friction movement requirements;
3. Specially engineered guide unit body enables multi-directional mounting configurations for flexible installation.
Category: Guide Units | Brand: AirTAC | Series: F-TMIL
AirTAC F-TMIL12X200 Linear Guide Bracket Complete Package Specifications
- Model: F-TMIL12X200
- Type: Precision Linear Motion Guide Assembly
- Shaft diameter: 12mm (chrome-plated steel)
- Effective stroke: 200mm
- Material: Aluminum alloy bracket + Carbon steel shaft
- Static load capacity: 1,200N (radial)
- Dynamic load capacity: 800N (radial)
- Mounting hole spacing: 50mm × 40mm (standard M5 threads)
- Surface hardness: HRC58-62 (shaft)
- Operating temperature: -20℃ to 120℃
- Lubrication: Pre-lubricated with lithium complex grease
- Weight: 1.85kg ±2%
- Dimensions: 280mm(L) × 45mm(W) × 32mm(H)
Precision-engineered linear guidance system featuring zero-backlash operation and corrosion-resistant construction. The hardened shaft and optimized ball bearing arrangement ensure smooth reciprocating motion with ±0.01mm repeat positioning accuracy. Includes pre-assembled mounting hardware and alignment shims.
- 3D printer Z-axis stabilization systems
- Laser cutting machine optical carriage
- Automated test equipment probe positioning
- Semiconductor wafer handling robots
- Medical imaging device sliding mechanisms
Installation note:
Ensure parallel alignment within 0.05mm/m during mounting. Apply supplemental lubrication
every 500km of travel or 6 months (whichever comes first) using ISO VG32-grade grease.
| Property | Property Value |
|---|---|
| sku | F-TMIL12X200 |
| Bore Diameter | 12mm |
| Stroke | <200mm> |
