Airtac F-TMIL Guide Unit Assembly F-TMIL12X25
2. Sliding bushings: Ideal for applications requiring radial load resistance such as braking operations, offering enhanced torsional rigidity; Linear bushings: Suitable for pushing/lifting actions, high-precision scenarios, and heavy-load applications, particularly optimized for low-friction movement requirements;
3. Specially engineered guide unit body enables multi-directional mounting configurations for flexible installation.
Category: Guide Units | Brand: AirTAC | Series: F-TMIL
AirTAC F-TMIL12X25 Linear Guide Bracket Complete Kit Specifications
- Model: F-TMIL12X25
- Type: Linear motion guide assembly with integrated bearing blocks
- Bore diameter: 12mm (precision ground)
- Stroke length: 25mm (standard travel)
- Material: Aluminum alloy body with chrome-plated steel guide rod
- Load capacity: 15kg dynamic / 30kg static
- Precision grade: C7 class (±0.05mm/m accuracy)
- Mounting hole spacing: 20mm (M4 threaded holes)
- Surface treatment: Hard anodized (Aluminum) + anti-corrosion coating
- Operating temperature: -20℃ to 120℃
- Lubrication: Pre-lubricated with MX-200 grease (maintenance-free for 5,000km travel)
- Weight: 480g ±5%
- Dimensions: 52mm(W) × 38mm(H) × 87mm(L)
- Certification: ISO 6432 compliant
Precision-engineered linear motion solution combining low-friction movement with high rigidity. Features dual sealed bearing blocks with wiper seals that prevent particulate ingress (IP54 equivalent). The modular design allows direct integration with pneumatic cylinders or as standalone linear guides. Includes mounting hardware and alignment shims.
- Pick-and-place robot end effectors
- CNC machine tool accessory slides
- Automated test equipment positioning stages
- Semiconductor wafer handling systems
- Food packaging vertical lift mechanisms
Installation note:
Use 0.02mm feeler gauge to verify parallel alignment during mounting.
Apply thread locker (medium strength) to M4 fasteners. Maximum recommended
installation torque: 1.2N·m. Requires 50-hour run-in period at 50% load capacity.
| Property | Property Value |
|---|---|
| sku | F-TMIL12X25 |
| Bore Diameter | 12mm |
| Stroke | <25 mm> |
