This model is discontinued
AirTAC has phased out the ACP series. You can still order this code here: we ship the current replacement ACEJ12X10-10, the same code under the new prefix. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.
Airtac ACPJ Adjustable Compact Cylinder ACPJ12X10-10
The AirTAC ACPJ Adjustable Compact Cylinder ACPJ12X10-10 is a double acting, double rod, adjustable stroke DIN-standard tight/compact air cylinder with a Ø12mm bore and 10mm stroke, M5×0.8 air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ACEJ12X10-10 (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ12 mm
- Stroke10 mm
- Port sizeM5×0.8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM3×0.5
- StatusDiscontinued → ACEJ12X10-10
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACPJ Adjustable Compact Cylinder ACPJ12X10-10
The ACPJ12X10-10 is a double acting compact cylinder with an adjustable extend stroke: the -10 code gives a 10 mm window, so a stop screw trims the 10 mm stroke anywhere from 0 to 10 mm on site. It is a DIN-standard short-body unit, not an ISO 15552 profile cylinder, and the hard-anodized aluminium body saves about 50% of the mounting length of an ISO 15552 profile cylinder - ideal where a 12 mm bore must fit inside a tight jig or guard. At 0.5 MPa it pushes 56.5 N and pulls 42.4 N; at 0.7 MPa that rises to 79.2 N push and 59.4 N pull, with a theoretical 11.5 kgf at 1.0 MPa.
Practically, plan on roughly 34 N of real work at 0.5 MPa (about 60% of the rated push), which corresponds to lifting about 3 kg vertically - halve that to around 1.5 kg if you want a 2:1 margin when matching a part weight. The rod is 6 mm with a female M3x0.5 thread, the port is M5x0.8, and a fixed TPU bumper sits at both ends. Note this model is DISCONTINUED: the current-production drop-in is the ACEJ12X10 (swap the P for an E), so confirm ISO 21287 mounting dimensions before swapping. Also note the adjuster is a mechanical end stop only - on air loss the piston still drifts, so it never holds a load.
Airtac ACPJ Adjustable Compact Cylinder ACPJ12X10-10 Technical Specifications
| Model | Airtac ACPJ Adjustable Compact Cylinder ACPJ12X10-10 |
|---|---|
| Series | ACPJ DIN compact cylinder (discontinued) |
| Replacement | ACEJ12X10-10 |
| Bore size | Ø12 mm |
| Stroke | 10 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | M5×0.8 |
| Rod thread | M3×0.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 50 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ACEJ12X10-10 (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø12mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 42 N |
| 0.7 MPa | 59 N |
| Max (@1.0 MPa) | 9 kgf |
ACPJ is double-rod: the rear rod that carries the stroke adjuster exits the rear cover, so both piston faces lose rod area. The rod-side (annular) area is used for both directions (conservative).
Model Code: Airtac ACPJ Adjustable Compact Cylinder ACPJ12X10-10
| ACPJ | DIN compact cylinder (adjustable-stroke, discontinued). |
|---|---|
| 12 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| -10 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (double rod, adjustable stroke).
Where the Airtac ACPJ Adjustable Compact Cylinder ACPJ12X10-10 Is Used
Micro clamp on a PCB test fixture
The 10 mm adjustable stroke (trimmable 0-10 mm) seats a probe block onto small circuit boards; 56.5 N push at 0.5 MPa is enough for light hold-down without damaging components.
Ejector in a small assembly head
A 6 mm rod with M3x0.5 female thread drives a knockout pin that pushes a pressed bushing out of a locating nest; the short body fits where a full-length cylinder cannot.
Gate trigger on a packaging line
Order the -S version with a CMSE or DMSE switch to confirm the gate is fully extended before the filler nozzle fires; the 12 mm bore reacts fast at 30-500 mm/s.
Replacing the Airtac ACPJ Adjustable Compact Cylinder ACPJ12X10-10 with the ACEJ12X10-10
Size both ways: if 56.5 N of push at 0.5 MPa is marginal for your clamp or eject job, step up to the 16 mm bore (100.5 N push at 0.5 MPa); if 56.5 N is far more than needed, the same ACPJ family starts at this 12 mm bore, so this is already the smallest force class. Match the mounting to the fixture - FA/FB flange or LB foot bolt to the standard face, with I/Y knuckles available for the 6 mm rod. If you need position sensing, order the -S variant: without the optional -S magnet code there is no magnet and no CMSE / DMSE switch can be fitted. Replacement: order the ACEJ12X10, the current ISO 21287 successor in the same bore, stroke and force class.
Replacement checklist
- ✓ Current-production ACE → ACEJ12X10-10
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ACPJ Adjustable Compact Cylinder ACPJ12X10-10 FAQ
At 0.5 MPa it pushes 56.5 N and pulls 42.4 N; at 0.7 MPa it pushes 79.2 N and pulls 59.4 N; theoretical maximum is 11.5 kgf at 1.0 MPa. The -10 code is a 10 mm adjustment window: a stop screw shortens the 10 mm extend stroke within that window, giving a usable range of 0-10 mm. It shortens the stroke only - it never extends past the ordered 10 mm, and it is a mechanical stop, not a load-holding lock. Operating pressure is 0.15-1.0 MPa (22-145 psi), speed 30-500 mm/s, with a fixed TPU bumper at both ends.
No - the ACPJ12X10-10 is discontinued. The current-production replacement is the ACEJ12X10, an ISO 21287 compact cylinder in the same 12 mm bore, 10 mm stroke and force class. The ACP is DIN-standard, so confirm the ISO 21287 mounting dimensions (FA/FB flange or LB foot hole pattern) before swapping. The replacement keeps the M5x0.8 port and the 6 mm rod, and the optional -S magnet code enables CMSE / DMSE switches just like the original.
