This model is discontinued
AirTAC has phased out the ACP series. You can still order this code here: we ship the current replacement ACEJ12X10-10B, the same code under the new prefix. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.
Airtac ACPJ Adjustable Compact Cylinder ACPJ12X10-10B
The AirTAC ACPJ Adjustable Compact Cylinder ACPJ12X10-10B is a double acting, double rod, adjustable stroke DIN-standard tight/compact air cylinder with a Ø12mm bore and 10mm stroke, M5×0.8 air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ACEJ12X10-10B (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ12 mm
- Stroke10 mm
- Port sizeM5×0.8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM3×0.5
- StatusDiscontinued → ACEJ12X10-10B
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACPJ Adjustable Compact Cylinder ACPJ12X10-10B
Double acting compact cylinder with an adjustable extend stroke, the ACPJ12X10-10B uses a 12 mm bore and a 10 mm base stroke that a stop screw trims anywhere in the 0-10 mm range via the -10 window. At 0.5 MPa it pushes 56.5 N and pulls 42.4 N, rising to 79.2 N push at 0.7 MPa, with a theoretical peak of 11.5 kgf at 1.0 MPa. The male rod thread (B code) gives a 6 mm rod you can screw straight into your tooling. Note: this model is discontinued - the current drop-in is ACEJ12X10, so confirm ISO 21287 mounting dimensions before swapping.
The short ISO 21287-class body saves roughly 50% of the mounting length of an ISO 15552 profile cylinder, which is why it suits slim pick-and-place heads and cramped fixtures. Plan on about 34 N (roughly 2.8 kg vertical lift with a 2:1 margin) of usable force rather than the full 56.5 N rating. Fixed TPU bumpers sit at both ends, speed runs 30-500 mm/s, and the body is hard-anodized aluminium with an S45C hard-chrome rod. No magnet is fitted on this version; order the -S code if you later need CMSE / DMSE switch sensing.
Airtac ACPJ Adjustable Compact Cylinder ACPJ12X10-10B Technical Specifications
| Model | Airtac ACPJ Adjustable Compact Cylinder ACPJ12X10-10B |
|---|---|
| Series | ACPJ DIN compact cylinder (discontinued) |
| Replacement | ACEJ12X10-10B |
| Bore size | Ø12 mm |
| Stroke | 10 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | M5×0.8 |
| Rod thread | M3×0.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 50 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ACEJ12X10-10B (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø12mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 42 N |
| 0.7 MPa | 59 N |
| Max (@1.0 MPa) | 9 kgf |
ACPJ is double-rod: the rear rod that carries the stroke adjuster exits the rear cover, so both piston faces lose rod area. The rod-side (annular) area is used for both directions (conservative).
Model Code: Airtac ACPJ Adjustable Compact Cylinder ACPJ12X10-10B
| ACPJ | DIN compact cylinder (adjustable-stroke, discontinued). |
|---|---|
| 12 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| -10 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (double rod, adjustable stroke).
Where the Airtac ACPJ Adjustable Compact Cylinder ACPJ12X10-10B Is Used
Micro part ejection
Trims a 0-10 mm extend stroke to nudge small machined pins off a fixture, with the 56.5 N push at 0.5 MPa enough for gram-range parts.
Compact test station actuator
The short body fits inside a benchtop go/no-go gauge where an ISO 15552 profile cylinder would not; add the -S magnet code if switch feedback is needed later.
Light lid press on lab automation
Male 6 mm rod thread screws directly into a press head to seat sample-plate lids using about 34 N of practical working force.
Replacing the Airtac ACPJ Adjustable Compact Cylinder ACPJ12X10-10B with the ACEJ12X10-10B
At 56.5 N push (0.5 MPa) this 12 mm bore covers light clamping and part-presenting tasks; step up to the 16 mm bore (100.5 N push) if your load creeps past about 34 N of real work. The 0-10 mm adjustable range only shortens the extend stroke - it is a mechanical end stop, not a mid-stroke lock, so the rod still drifts if air is lost. FA/FB flange or LB foot mounts bolt to the ISO 21287 face. Since ACPJ is discontinued, spec ACEJ12X10 for new builds and verify mounting dimensions.
Replacement checklist
- ✓ Current-production ACE → ACEJ12X10-10B
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ACPJ Adjustable Compact Cylinder ACPJ12X10-10B FAQ
Push is 56.5 N and pull 42.4 N at 0.5 MPa; at 0.7 MPa push is 79.2 N and pull 59.4 N, with a theoretical maximum of 11.5 kgf at 1.0 MPa. Bore is 12 mm, stroke 10 mm adjustable over a 0-10 mm window, rod 6 mm with male thread, port M5x0.8 (PT), speed 30-500 mm/s, pressure 0.15-1.0 MPa (22-145 psi), proof 1.5 MPa (215 psi).
The -10 code gives a 10 mm adjustment window: an external stop screw shortens the extend stroke anywhere from 0 to 10 mm, though it cannot lengthen the stroke past the ordered 10 mm. The ACPJ family is discontinued; the current-production replacement is ACEJ12X10 in the same bore, stroke and force class - confirm the ISO 21287 mounting dimensions before swapping.
