This model is discontinued
AirTAC has phased out the ACP series. You can still order this code here: we ship the current replacement ACEJ12X100-100SB, the same code under the new prefix. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.
Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-100SB
The AirTAC ACPJ Adjustable Compact Cylinder ACPJ12X100-100SB is a double acting, double rod, adjustable stroke DIN-standard tight/compact air cylinder with a Ø12mm bore and 100mm stroke, M5×0.8 air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ACEJ12X100-100SB (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ12 mm
- Stroke100 mm
- Port sizeM5×0.8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM3×0.5
- StatusDiscontinued → ACEJ12X100-100SB
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-100SB
Double acting and adjustable in stroke, the ACPJ12X100-100SB is a DIN-standard compact cylinder with a 12 mm bore and a 100 mm stroke trimmed by an external stop screw. The -100 code gives a full 100 mm adjustment window, so the extend stroke can be set anywhere from 0 to 100 mm on site. This unit carries the -S magnet and the B male rod thread, and it pushes 56.5 N and pulls 42.4 N at 0.5 MPa.
The short ISO 21287-class body saves about 50% of the mounting length of an ISO 15552 profile cylinder, which is why it slots into tight test fixtures and small assembly heads. Plan on roughly 34 N of real work at 0.5 MPa (about 60% of the push rating), which lifts about 3 kg vertically with a 2:1 margin. Note the 100 mm stroke exceeds the 50 mm maximum standard stroke for bore 12, so it is a made-to-order build. This model is discontinued; the current-production replacement is the ACEJ12X100, so confirm ISO 21287 mounting dimensions before swapping.
Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-100SB Technical Specifications
| Model | Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-100SB |
|---|---|
| Series | ACPJ DIN compact cylinder (discontinued) |
| Replacement | ACEJ12X100-100SB |
| Bore size | Ø12 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | M5×0.8 |
| Rod thread | M3×0.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 50 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ACEJ12X100-100SB (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø12mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 42 N |
| 0.7 MPa | 59 N |
| Max (@1.0 MPa) | 9 kgf |
ACPJ is double-rod: the rear rod that carries the stroke adjuster exits the rear cover, so both piston faces lose rod area. The rod-side (annular) area is used for both directions (conservative).
Model Code: Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-100SB
| ACPJ | DIN compact cylinder (adjustable-stroke, discontinued). |
|---|---|
| 12 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -100 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (double rod, adjustable stroke).
Where the Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-100SB Is Used
Lab sample ejector
The 34 N usable push at 0.5 MPa is enough to eject microplate samples or slide trays from a compact analytical station, with the stroke trimmed to the exact tray depth.
Small-part press fit
Light press work such as seating pins into PCB connectors suits the 56.5 N push at 0.5 MPa, and the male rod thread takes an I knuckle for a floating joint.
Gated indexing fixture
With the -S magnet fitted, CMSE or DMSE switches confirm extend and retract positions on a 0-100 mm indexing slide inside a guard where a full-length cylinder will not fit.
Replacing the Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-100SB with the ACEJ12X100-100SB
At 12 mm bore this is the smallest force class in the range: 56.5 N push at 0.5 MPa. Step up to the 16 mm bore for 100.5 N push or the 20 mm bore for 157.1 N push at the same pressure if your part weight grows. The stop screw is a mechanical end stop for the extend stroke only, not a mid-stroke lock, so the piston can still drift on air loss. FA/FB flange and LB foot mountings bolt to the ISO 21287 face, and CMSE or DMSE switches mount because the -S magnet is fitted on this model. Order the ACEJ12X100 as the current drop-in replacement.
Replacement checklist
- ✓ Current-production ACE → ACEJ12X100-100SB
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-100SB FAQ
At 0.5 MPa it pushes 56.5 N and pulls 42.4 N; at 0.7 MPa it pushes 79.2 N and pulls 59.4 N. The theoretical maximum is 11.5 kgf at 1.0 MPa. Operating pressure is 0.15-1.0 MPa (22-145 psi) with a 1.5 MPa (215 psi) proof pressure, speed 30-500 mm/s, and the 100 mm stroke is a made-to-order length above the 50 mm standard maximum for bore 12.
A stop screw shortens the 100 mm extend stroke by up to 100 mm, giving a usable 0-100 mm range; it is an end stop, not a load-holding lock. The ACPJ family is discontinued, and the ACEJ12X100 is the current-production ISO 21287 replacement in the same bore, stroke and force class - confirm the mounting dimensions before swapping.
Related AirTAC ACE Cylinders
Request a Quote for the ACEJ12X100-100SB
Send us the quantity and destination. We confirm price, stock and lead time on the ACEJ12X100-100SB replacement — usually within 7-8 hours.
